FN2020B-16-06
ActiveTE Connectivity Raychem Cable Protection
LINE FILTER 250VAC 16A CHASSIS
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
FN2020B-16-06
ActiveTE Connectivity Raychem Cable Protection
LINE FILTER 250VAC 16A CHASSIS
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | FN2020B-16-06 |
|---|---|
| Applications | General Purpose |
| Approval Agency | CSA, ENEC, UR |
| Configuration | Single Stage |
| Current | 16 A |
| Filter Type | Single Phase |
| Frequency - Operating | 400 Hz |
| Inductance | 650 µH |
| Mounting Type | Chassis Mount |
| Operating Temperature [custom] | 100 °C, -25 °C |
| Termination Style | Quick Connect |
| Voltage - Rated AC | 250 V |
Schaffner FN2020 Series
| Part | Applications | Configuration | Current | Operating Temperature [custom] | Filter Type | Frequency - Operating | Termination Style | Voltage - Rated AC | Mounting Type | Inductance | Approval Agency |
|---|---|---|---|---|---|---|---|---|---|---|---|
TE Connectivity Raychem Cable Protection | Safety | Single Stage | 20 A | -25 °C 100 °C | Single Phase | 400 Hz | Quick Connect | 250 V | Chassis Mount | 600 µH | CSA ENEC UR |
TE Connectivity Raychem Cable Protection | General Purpose | Single Stage | 12 A | -25 °C 100 °C | Single Phase | 400 Hz | Quick Connect | 250 V | Chassis Mount | 700 µH | CSA ENEC UR |
TE Connectivity Raychem Cable Protection | General Purpose | Single Stage | 16 A | -25 °C 100 °C | Single Phase | 400 Hz | Quick Connect | 250 V | Chassis Mount | 650 µH | CSA ENEC UR |
TE Connectivity Raychem Cable Protection | General Purpose | Single Stage | 16 A | -25 °C 100 °C | Single Phase | 400 Hz | Threaded Post (M4) | 250 V | Chassis Mount | 650 µH | CSA ENEC UR |
TE Connectivity Raychem Cable Protection | General Purpose | Single Stage | 1 A | -25 °C 100 °C | Single Phase | 400 Hz | Quick Connect | 250 V | Chassis Mount | 12 mH | CSA ENEC UR |
TE Connectivity Raychem Cable Protection | General Purpose | Single Stage | 20 A | -25 °C 100 °C | Single Phase | 400 Hz | Quick Connect | 250 V | Chassis Mount | 600 µH | CSA ENEC UR |
TE Connectivity Raychem Cable Protection | Safety | Single Stage | 10 A | -25 °C 100 °C | Single Phase | 400 Hz | Quick Connect | 250 V | Chassis Mount | 800 µH | CSA ENEC UR |
TE Connectivity Raychem Cable Protection | Safety | Single Stage | 30 A | -25 °C 100 °C | Single Phase | 400 Hz | Threaded Post (M4) | 250 V | Chassis Mount | 670 µH | CSA ENEC UR |
TE Connectivity Raychem Cable Protection | General Purpose | Single Stage | 10 A | -25 °C 100 °C | Single Phase | 400 Hz | Quick Connect | 250 V | Chassis Mount | 800 µH | CSA ENEC UR |
TE Connectivity Raychem Cable Protection | General Purpose | Single Stage | 16 A | -25 °C 100 °C | Single Phase | 400 Hz | Quick Connect | 250 V | Chassis Mount | 650 µH | CSA ENEC UR |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 1 | $ 18.64 | |
Description
General part information
Schaffner FN2020 Series
Single Phase EMC/EMI Line Filter 16 A 250V DC ~ 400Hz Single Stage Quick Connect
