AR03DTC1503

Active

Viking Tech

RES 150K OHM 0.5% 1/16W 0603

Search across all available documentation for this part.

Active

Viking Tech

RES 150K OHM 0.5% 1/16W 0603

Technical Specifications

Parameters and characteristics commom to parts in this series

RES 47K OHM 0.5% 1/16W 0603

Part	Temperature Coefficient	Composition	Operating Temperature [Max]	Operating Temperature [Min]	Package / Case	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Resistance	Number of Terminations	Power (Watts)	Power (Watts)	Ratings	Features
Viking Tech AR03DTC4702	25 ppm/°C	Thin Film	155 °C	-55 °C	0603 (1608 Metric)	0.022 in	0.55 mm	47 kOhms	2	0.0625 W	0.063 W
Viking Tech AR03DTC2002	25 ppm/°C	Thin Film	155 °C	-55 °C	0603 (1608 Metric)	0.022 in	0.55 mm	20 kOhms	2	0.0625 W	0.063 W
Viking Tech AR03DTC1004	25 ppm/°C	Thin Film	155 °C	-55 °C	0603 (1608 Metric)	0.022 in	0.55 mm	1 MOhms	2	0.0625 W	0.063 W
Viking Tech AR03DTC7503	25 ppm/°C	Thin Film	155 °C	-55 °C	0603 (1608 Metric)	0.022 in	0.55 mm	750000 Ohms	2	0.0625 W	0.063 W
Viking Tech AR03DTC4700	25 ppm/°C	Thin Film	155 °C	-55 °C	0603 (1608 Metric)	0.022 in	0.55 mm	470 Ohms	2	0.0625 W	0.063 W
Viking Tech AR03DTC1301A	25 ppm/°C	Thin Film	155 °C	-55 °C	0603 (1608 Metric)	0.022 in	0.55 mm	1.3 kOhms	2	0.0625 W	0.063 W	AEC-Q200	Automotive AEC-Q200
Viking Tech AR03DTC4991	25 ppm/°C	Thin Film	155 °C	-55 °C	0603 (1608 Metric)	0.022 in	0.55 mm	4.99 kOhms	2	0.0625 W	0.063 W
Viking Tech AR03DTC4990	25 ppm/°C	Thin Film	155 °C	-55 °C	0603 (1608 Metric)	0.022 in	0.55 mm		2	0.0625 W	0.063 W
Viking Tech AR03DTC1002	25 ppm/°C	Thin Film	155 °C	-55 °C	0603 (1608 Metric)	0.022 in	0.55 mm	10000 Ohms	2	0.0625 W	0.063 W
Viking Tech AR03DTC5101	25 ppm/°C	Thin Film	155 °C	-55 °C	0603 (1608 Metric)	0.022 in	0.55 mm	5.1 kOhms	2	0.0625 W	0.063 W

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tape & Reel (TR)	1	$ 0.01

General part information

150 kOhms ±0.5% 0.063W, 1/16W Chip Resistor 0603 (1608 Metric) Thin Film

Technical documentation and resources

No documents available
