120-A-111/03

Active

WECO Electrical Connectors Inc.

PLUG PLUG-IN SCREW; 3POS 5MM PIT

Search across all available documentation for this part.

Active

WECO Electrical Connectors Inc.

PLUG PLUG-IN SCREW; 3POS 5MM PIT

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

3 Position Terminal Block Plug, Female Sockets 0.197" (5.00mm) 180° Free Hanging (In-Line)

Specification	120-A-111/03	120-A-11 Series

Color	Gray	Gray
Contact Material	Copper Alloy	Copper Alloy
Contact Mating Finish	Tin	Tin
Housing Material	Polyamide (PA), Nylon	Polyamide (PA), Nylon
Insulation Height	0.59 in	0.59 in
Insulation Height	14.99 mm	14.99 mm
Material Flammability Rating	UL94 V-0	UL94 V-0
Mounting Type	Free Hanging (In-Line)	Free Hanging (In-Line)
Number of Levels	1	1
Number of Positions	-	6
Operating Temperature [Max]	105 ░C	105 ░C
Operating Temperature [Min]	-40 °C	-40 °C
Pitch [x]	5 mm	5 mm
Pitch [x]	0.197 in	0.197 in
Positions Per Level	3	3 - 6
Screw Size	M3	M3
Termination Style	Screw - Rising Cage Clamp	Screw - Rising Cage Clamp
Torque - Screw	0.51 Nm	0.51 Nm
Torque - Screw	4.5 Lb-In	4.5 Lb-In
Type	Plug, Female Sockets	Plug, Female Sockets
Voltage - UL	300 V	300 V
Wire Gauge or Range - AWG [Max]	26 AWG	26 AWG
Wire Gauge or Range - AWG [Min]	12 AWG	12 AWG
Wire Gauge or Range - mm²	2.5 mm²	2.5 mm²
Wire Strip Length	7 mm	7 mm

Part	Voltage - UL	Contact Mating Finish	Operating Temperature [Min]	Operating Temperature [Max]	Material Flammability Rating	Insulation Height	Insulation Height	Number of Levels	Wire Gauge or Range - mm²	Housing Material	Pitch [x]	Pitch [x]	Color	Contact Material	Positions Per Level	Screw Size	Wire Gauge or Range - AWG [Min]	Wire Gauge or Range - AWG [Max]	Mounting Type	Torque - Screw	Torque - Screw	Number of Positions	Wire Strip Length	Termination Style	Type
WECO Electrical Connectors Inc. 120-A-111/06	300 V	Tin	-40 °C	105 ░C	UL94 V-0	0.59 in	14.99 mm	1	2.5 mm²	Polyamide (PA), Nylon	5 mm	0.197 in	Gray	Copper Alloy	6	M3	12 AWG	26 AWG	Free Hanging (In-Line)	0.51 Nm	4.5 Lb-In	6	7 mm	Screw - Rising Cage Clamp	Plug, Female Sockets
WECO Electrical Connectors Inc. 120-A-111/03	300 V	Tin	-40 °C	105 ░C	UL94 V-0	0.59 in	14.99 mm	1	2.5 mm²	Polyamide (PA), Nylon	5 mm	0.197 in	Gray	Copper Alloy	3	M3	12 AWG	26 AWG	Free Hanging (In-Line)	0.51 Nm	4.5 Lb-In		7 mm	Screw - Rising Cage Clamp	Plug, Female Sockets
