RNHT0603BTE576R
ActiveStackpole Electronics Inc
RES AUTO, 576 OHM, 0603, 0.1%, 2
RNHT0603BTE576R
ActiveStackpole Electronics Inc
RES AUTO, 576 OHM, 0603, 0.1%, 2
Description
General part information
RNHT0603BTE576R
576 Ohms ±0.1% 0.1W, 1/10W Chip Resistor 0603 (1608 Metric) Anti-Sulfur, Automotive AEC-Q200 Thin Film
Technical Specifications
Parameters and characteristics for this part
| Specification | RNHT0603BTE576R |
|---|---|
| Composition | Thin Film |
| Features | Automotive AEC-Q200, Anti-Sulfur |
| Height - Seated (Max) | 0.022 in |
| Number of Terminations | 2 |
| Operating Temperature (Max) | 155 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | 0603 (1608 Metric) |
| Package Name | 0603 |
| Power (Watts) | 100 mW |
| Power (Watts) Options | 1/10W |
| Ratings | AEC-Q200 |
| Resistance | 576 Ohm |
| Size / Dimension Length | 0.061 in |
| Size / Dimension Width | 0.031 in |
| Temperature Coefficient | 25 ppm/°C |
| Tolerance | 0.1 % |
