0420CDMCBDS-R22MC
ObsoleteSumida America Components Inc.
FIXED IND 220NH 10.1A 5.3MOHM SM
0420CDMCBDS-R22MC
ObsoleteSumida America Components Inc.
FIXED IND 220NH 10.1A 5.3MOHM SM
Description
General part information
0420CDMCBDS-R22MC
220 nH Shielded Wirewound Inductor 10.1 A 5.3mOhm 2-SMD
Technical Specifications
Parameters and characteristics for this part
| Specification | 0420CDMCBDS-R22MC |
|---|---|
| Current - Saturation (Isat) | 15 A |
| Current Rating | 10.1 A |
| DC Resistance (DCR) | 5.3 mOhm |
| Height - Seated (Max) | 0.079 in |
| Inductance | 220 nH |
| Inductance Frequency - Test | 100 kHz |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | 2-SMD |
| Package Name | SMD |
| Shielding | Shielded |
| Size / Dimension Length | 0.177 in |
| Size / Dimension Width | 0.161 in |
| Tolerance | 20 % |
| Type | Wirewound |
