H7WXH-3706G

Active

Assmann WSW Components

CABLE ASSY DB37 GRAY 1.83M

Search across all available documentation for this part.

Active

Assmann WSW Components

CABLE ASSY DB37 GRAY 1.83M

Technical Specifications

Parameters and characteristics commom to parts in this series

CABLE ASSY DB37 GRAY 1.83M

Part	Length	Length	Type	1st Connector	2nd Connector	Contact Finish Thickness	Contact Finish Thickness	Shielding	Contact Finish	Number of Positions	Color
Assmann WSW Components H7WXH-3706G	6 ft	1.83 m	DB37	Female Sockets, Receptacle	Individual Wire Leads	10 Áin	0.25 Ám	Unshielded	Gold	37
Assmann WSW Components H7WXH-3710M	10 ft	3.05 m	DB37	Female Sockets, Receptacle	Individual Wire Leads	10 Áin	0.25 Ám	Unshielded	Gold	37	Multiple, Ribbon
Assmann WSW Components H7WXH-3706M	6 ft	1.83 m	DB37	Female Sockets, Receptacle	Individual Wire Leads	10 Áin	0.25 Ám	Unshielded	Gold	37	Multiple, Ribbon

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

D-Sub Cable Assembly DB37 Gray, Ribbon 6.00' (1.83m) Receptacle, Female Sockets to Individual Wire Leads Unshielded

Technical documentation and resources

No documents available
