F9460PC 1"X60YD

Active

TAPE ADHSV TRNSFR CLR 1"X60YDS

Search across all available documentation for this part.

Active

TAPE ADHSV TRNSFR CLR 1"X60YDS

Technical Specifications

Parameters and characteristics for this part

Specification	F9460PC 1"X60YD

Adhesive	Acrylic, 100MP
Backing, Carrier	Polycoated Kraft Liner
Color	Clear
Length	60 yds
Length	55 m
Length	180 ft
Shelf Life	24 Months
Shelf Life Start	Date of Manufacture
Storage/Refrigeration Temperature [Max]	80 °F, 27 °C
Storage/Refrigeration Temperature [Min]	60 °F, 16 °C
Tape Type	Adhesive Transfer
Temperature Range	300 °F
Temperature Range	149 °C
Thickness	0.006 in
Thickness	0.152 mm
Thickness	6 mils
Thickness - Adhesive	2 mils
Thickness - Adhesive	0.051 mm
Thickness - Adhesive [x]	0.002 "
Thickness - Backing, Carrier	0.102 mm
Thickness - Backing, Carrier	4 mils
Thickness - Backing, Carrier	0.004 in
Usage	High Temperature Applications, Attachment
Width [x]	25.4 mm
Width [x]	1 in

TAPE ADHSV TRNSFR CLR 1"X60YDS

Part	Thickness	Thickness	Thickness	Shelf Life Start	Thickness - Backing, Carrier	Thickness - Backing, Carrier	Thickness - Backing, Carrier	Thickness - Adhesive	Thickness - Adhesive	Thickness - Adhesive [x]	Backing, Carrier	Width [x]	Width [x]	Tape Type	Color	Length	Length	Length	Adhesive	Usage	Temperature Range	Temperature Range	Storage/Refrigeration Temperature [Min]	Storage/Refrigeration Temperature [Max]	Shelf Life
3M F9460PC 1"X60YD	0.006 in	0.152 mm	6 mils	Date of Manufacture	0.102 mm	4 mils	0.004 in	2 mils	0.051 mm	0.002 "	Polycoated Kraft Liner	25.4 mm	1 in	Adhesive Transfer	Clear	60 yds	55 m	180 ft	Acrylic, 100MP	Attachment, High Temperature Applications	300 °F	149 °C	16 °C, 60 °F	27 °C, 80 °F	24 Months

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Adhesive Transfer Tape Acrylic, 100MP Adhesive Clear 1.00" (25.40mm) X 180' (55.0m) 60 yds
