Technical Specifications
Parameters and characteristics for this part
| Specification | D38999/26TC4HA |
|---|---|
| Applications | Aerospace, Aviation, Military, Marine |
| Connector Type | Plug, Male Pins |
| Contact Finish - Mating | Gold |
| Contact Material | Copper Alloy |
| Features | Self Locking |
| Grade | Military |
| Ingress Protection | Weathertight |
| Insert Material | Thermoplastic |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Free Hanging (In-Line) |
| Number of Positions | 4 |
| Operating Temperature [Max] | 150 °C |
| Operating Temperature [Min] | -65 ░C |
| Orientation | A |
| Qualification | MIL-DTL-38999 Series II |
| Shell Size - Insert | 13-4 |
| Shell Size, MIL | C |
| Shielding | Shielded |
| Termination | Crimp |
| Voltage Rating | 500 VAC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 71.33 | |
| 10 | $ 69.14 | |||
| 25 | $ 67.07 | |||
| 50 | $ 65.13 | |||
| 100 | $ 63.29 | |||
| 250 | $ 61.56 | |||
| 500 | $ 59.92 | |||
| 1000 | $ 58.36 | |||
| 1500 | $ 57.61 | |||
Description
General part information
D38999/26TC Series
4 Position Circular Connector Plug, Male Pins Crimp
