Part	Color	Ingress Protection Description	Ingress Protection IP Rating	Shell Material	Fastening Type	Number of Positions	Primary Material	Contact Material	Shell Size - Insert	Shell Size - Insert	Operating Temperature (Max)	Operating Temperature (Min)	Orientation	Contact Finish - Mating	Termination	Current Rating	Mounting Feature	Contact Finish Thickness - Mating	Connector Type	Material Flammability Rating	Shell Finish	Mounting Type	Insert Material	Shielding
LEMO EEG.1B.304.CLV	Silver	Dust Protected	IP50	Brass	Push-Pull	4	Metal	Bronze	304	304	250 °C	-55 °C	G	Gold	Solder	6 A	Bulkhead Front Side Nut	59 µin	Female Sockets Receptacle	UL94 V-0	Chrome	Panel Mount Right Angle Through Hole	PEEK Polyetheretherketone	Shielded
LEMO EEG.1B.307.CLN	Silver	Dust Protected	IP50	Brass	Push-Pull	7	Metal	Bronze	307	307	250 °C	-55 °C	G	Gold	Solder	7 A	Bulkhead Front Side Nut	59 µin	Female Sockets Receptacle	UL94 V-0	Chrome	Panel Mount Through Hole	PEEK Polyetheretherketone	Shielded
LEMO EEG.1B.307.CYM	Silver	Dust Protected	IP50	Brass	Push-Pull	7	Metal	Bronze	307	307	250 °C	-55 °C	G	Gold	Crimp	7 A	Bulkhead Front Side Nut	59 µin	Female Sockets Receptacle	UL94 V-0	Chrome	Panel Mount	PEEK Polyetheretherketone	Shielded
LEMO EEG.1B.307.CLL	Silver	Dust Protected	IP50	Brass	Push-Pull	7	Metal	Bronze	307	307	250 °C	-55 °C	G	Gold	Solder Cup	7 A	Bulkhead Front Side Nut	59 µin	Female Sockets Receptacle	UL94 V-0	Chrome	Panel Mount	PEEK Polyetheretherketone	Shielded
LEMO EEG.1B.306.CYM	Silver	Dust Protected	IP50	Brass	Push-Pull	6	Metal	Bronze	306	306	250 °C	-55 °C	G	Gold	Crimp	7 A	Bulkhead Front Side Nut	59 µin	Female Sockets Receptacle	UL94 V-0	Chrome	Panel Mount	PEEK Polyetheretherketone	Shielded
LEMO EEG.1B.302.CYMY	Silver	Dust Protected	IP50	Brass	Push-Pull	2	Metal	Bronze	302	302	250 °C	-55 °C	G	Gold	Crimp	15 A	Bulkhead Front Side Nut	59 µin	Female Sockets Receptacle	UL94 V-0	Chrome	Panel Mount	PEEK Polyetheretherketone	Shielded
LEMO EEG.1B.306.CLL	Silver	Dust Protected	IP50	Brass	Push-Pull	6	Metal	Bronze	306	306	250 °C	-55 °C	G	Gold	Solder Cup	7 A	Bulkhead Front Side Nut	59 µin	Female Sockets Receptacle	UL94 V-0	Chrome	Panel Mount	PEEK Polyetheretherketone	Shielded
LEMO EEG.1B.310.CLN	Silver	Dust Protected	IP50	Brass	Push-Pull	10	Metal	Bronze	310	310	250 °C	-55 °C	G	Gold	Solder	2.5 A	Bulkhead Front Side Nut	59 µin	Female Sockets Receptacle	UL94 V-0	Chrome	Panel Mount Through Hole	PEEK Polyetheretherketone	Shielded
LEMO EEG.1B.306.CLN	Silver	Dust Protected	IP50	Brass	Push-Pull	6	Metal	Bronze	306	306	250 °C	-55 °C	G	Gold	Solder	7 A	Bulkhead Front Side Nut	59 µin	Female Sockets Receptacle	UL94 V-0	Chrome	Panel Mount Through Hole	PEEK Polyetheretherketone	Shielded
LEMO EEG.1B.305.CLV	Silver	Dust Protected	IP50	Brass	Push-Pull	5	Metal	Bronze	305	305	250 °C	-55 °C	G	Gold	Solder	6 A	Bulkhead Front Side Nut	59 µin	Female Sockets Receptacle	UL94 V-0	Chrome	Panel Mount Right Angle Through Hole	PEEK Polyetheretherketone	Shielded

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

FGG.1B.772.DN | Datasheet
