PSK2420-9EG

Active

Bel Power Solutions

DC/DC CONVERTER 24V 480W

Search across all available documentation for this part.

Active

Bel Power Solutions

DC/DC CONVERTER 24V 480W

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Enclosed, Conformal Coated DC DC Converter 1 Output 24V 20A 80V Input

Technical documentation and resources

No documents available

Parameters and characteristics commom to parts in this series

Specification	PSK2420-9EG	PSK2420 Series

Applications	Railway, ITE (Commercial)	Railway, ITE (Commercial)
Approval Agency	cCSAus, CE	cCSAus, CE
Current - Output (Max) [Max]	20 A	20 A
DC Voltage - Input (Max)	-	80 V
DC Voltage - Input (Min)	-	29 V
Efficiency	95 %	94 - 95 %
Features	-	Remote On/Off, Adjustable Output, Remote Sense
Input Type	-	DC
Mounting Type	Chassis Mount	Chassis Mount
Number of Outputs	1	1
Operating Temperature [Max]	71 °C	71 °C
Operating Temperature [Min]	-40 °C	-40 - -25 °C
Power (Watts)	480 W	480 W
Size / Dimension [x]	171 mm	171 - 171.9 mm
Size / Dimension [x]	6.73 in	6.73 - 6.77 in
Size / Dimension [y]	111 mm	111 - 168.5 mm
Size / Dimension [y]	4.37 "	2.36 - 4.37 "
Size / Dimension [z]	3.15 "	3.15 "
Size / Dimension [z]	80 mm	80 mm
Standard Number	-	60950-1
Type	Conformal Coated, Enclosed	Conformal Coated, Enclosed
Voltage - Input (Max) [Max]	80 V	80 V
Voltage - Input (Min) [Min]	29 V	29 V
Voltage - Output 1	24 V	24 V

DC/DC DIN RAIL SUPPLY 24V 480W

Part	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [y]	Number of Outputs	Applications	Voltage - Output 1	Features	Power (Watts)	Input Type	Standard Number	DC Voltage - Input (Max) [Max]	Efficiency	Approval Agency	Current - Output (Max) [Max]	DC Voltage - Input (Min) [Min]	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Voltage - Input (Max) [Max]	Type	Voltage - Input (Min) [Min]
Bel Power Solutions PSK2420-9EKB1G	4.37 "	171.9 mm	6.77 in	3.15 "	80 mm	111 mm	1	ITE (Commercial), Railway	24 V	Adjustable Output, Remote On/Off, Remote Sense	480 W	DC	60950-1	80 V	94 %	cCSAus, CE	20 A	29 V	71 °C	-40 °C
Bel Power Solutions PSK2420-9EG	4.37 "	171 mm	6.73 in	3.15 "	80 mm	111 mm	1	ITE (Commercial), Railway	24 V		480 W				95 %	cCSAus, CE	20 A		71 °C	-40 °C	Chassis Mount	80 V	Conformal Coated, Enclosed	29 V
Bel Power Solutions PSK2420-7EB	2.36 "	171 mm	6.73 in	3.15 "	80 mm	168.5 mm	1	ITE (Commercial), Railway	24 V		480 W				95 %	cCSAus, CE	20 A		71 °C	-25 °C	Chassis Mount	80 V	Conformal Coated, Enclosed	29 V
Bel Power Solutions PSK2420-9EC	4.37 "	171.9 mm	6.77 in	3.15 "	80 mm	111 mm	1	ITE (Commercial), Railway	24 V	Adjustable Output, Remote On/Off, Remote Sense	480 W	DC	60950-1	80 V	94 %	cCSAus, CE	20 A	29 V	71 °C	-40 °C
Bel Power Solutions PSK2420-7	4.37 "	171 mm	6.73 in	3.15 "	80 mm	111 mm	1	ITE (Commercial), Railway	24 V		480 W				94 %	cCSAus, CE	20 A		71 °C	-25 °C	Chassis Mount	80 V	Conformal Coated, Enclosed	29 V
