M1YXK-2636R
Active3M
IDC CABLE - MPD26K/MC26M/X
Deep-Dive with AI
Search across all available documentation for this part.
M1YXK-2636R
Active3M
IDC CABLE - MPD26K/MC26M/X
Deep-Dive with AI
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | M1YXK-2636R | M1YXK Series |
|---|---|---|
| Cable Termination | IDC | IDC |
| Color | Ribbon, Multiple | Multiple, Twisted Pair (Flat), Ribbon, Multiple |
| Connector Type | Plug to Cable | Plug to Cable |
| Contact Finish | Gold | Gold |
| Contact Finish Thickness | 0.76 Ám | 0.76 Ám |
| Contact Finish Thickness | 30 Áin | 30 Áin |
| Features | Polarizing Key, Strain Relief, Flange | Polarizing Key, Strain Relief, Flange |
| Length [x] | 3 ft | 3 - 3.34 ft |
| Length [x] | 914.4 mm | 1.02 - 914.4 mm |
| Number of Positions | 26 | 10 - 64 |
| Number of Positions | - | 16 |
| Number of Rows | 2 | 2 |
| Pitch - Cable | 0.05 " | 0.05 " |
| Pitch - Cable | 1.27 mm | 1.27 mm |
| Pitch - Connector | 0.1 in | 0.1 in |
| Pitch - Connector | 2.54 mm | 2.54 mm |
| Shielding | Unshielded | Unshielded |
M1YXK Series
IDC CABLE - MPD50K/MC50G/X
| Part | Cable Termination | Contact Finish | Shielding | Connector Type | Pitch - Cable | Pitch - Cable | Features | Pitch - Connector | Pitch - Connector | Number of Rows | Contact Finish Thickness | Contact Finish Thickness | Length [x] | Length [x] | Number of Positions | Color | Number of Positions |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
IDC | Gold | Unshielded | Plug to Cable | 0.05 " | 1.27 mm | Flange, Polarizing Key, Strain Relief | 0.1 in | 2.54 mm | 2 | 0.76 Ám | 30 Áin | 3 ft | 914.4 mm | 50 | |||
IDC | Gold | Unshielded | Plug to Cable | 0.05 " | 1.27 mm | Flange, Polarizing Key, Strain Relief | 0.1 in | 2.54 mm | 2 | 0.76 Ám | 30 Áin | 3 ft | 914.4 mm | 30 | |||
IDC | Gold | Unshielded | Plug to Cable | 0.05 " | 1.27 mm | Flange, Polarizing Key, Strain Relief | 0.1 in | 2.54 mm | 2 | 0.76 Ám | 30 Áin | 3 ft | 914.4 mm | 36 | |||
IDC | Gold | Unshielded | Plug to Cable | 0.05 " | 1.27 mm | Flange, Polarizing Key, Strain Relief | 0.1 in | 2.54 mm | 2 | 0.76 Ám | 30 Áin | 3.34 ft | 1.02 m | 60 | Multiple, Twisted Pair (Flat) | ||
IDC | Gold | Unshielded | Plug to Cable | 0.05 " | 1.27 mm | Flange, Polarizing Key, Strain Relief | 0.1 in | 2.54 mm | 2 | 0.76 Ám | 30 Áin | 3 ft | 914.4 mm | 10 | Multiple, Ribbon | ||
IDC | Gold | Unshielded | Plug to Cable | 0.05 " | 1.27 mm | Flange, Polarizing Key, Strain Relief | 0.1 in | 2.54 mm | 2 | 0.76 Ám | 30 Áin | 3.34 ft | 1.02 m | 20 | Multiple, Twisted Pair (Flat) | ||
IDC | Gold | Unshielded | Plug to Cable | 0.05 " | 1.27 mm | Flange, Polarizing Key, Strain Relief | 0.1 in | 2.54 mm | 2 | 0.76 Ám | 30 Áin | 3 ft | 914.4 mm | 10 | |||
IDC | Gold | Unshielded | Plug to Cable | 0.05 " | 1.27 mm | Flange, Polarizing Key, Strain Relief | 0.1 in | 2.54 mm | 2 | 0.76 Ám | 30 Áin | 3 ft | 914.4 mm | 20 | |||
IDC | Gold | Unshielded | Plug to Cable | 0.05 " | 1.27 mm | Flange, Polarizing Key, Strain Relief | 0.1 in | 2.54 mm | 2 | 0.76 Ám | 30 Áin | 3 ft | 914.4 mm | 24 | |||
IDC | Gold | Unshielded | Plug to Cable | 0.05 " | 1.27 mm | Flange, Polarizing Key, Strain Relief | 0.1 in | 2.54 mm | 2 | 0.76 Ám | 30 Áin | 3 ft | 914.4 mm | 34 |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 23.78 | |
| 10 | $ 18.33 | |||
| 25 | $ 16.59 | |||
| 50 | $ 15.42 | |||
| 100 | $ 14.36 | |||
| 250 | $ 13.11 | |||
| 500 | $ 12.27 | |||
Description
General part information
M1YXK Series
26 Position Cable Assembly Rectangular Plug to Cable 3.00' (914.40mm)
