Description
General part information
400LSW4700M77X115
4700 µF 400 V Aluminum Electrolytic Capacitors Radial, Can - Screw Terminals 3000 Hrs @ 105°C
Technical Specifications
Parameters and characteristics for this part
| Specification | 400LSW4700M77X115 |
|---|---|
| Applications | General Purpose |
| Capacitance | 4700 µF |
| Height - Seated (Max) | 4.646 in |
| Lead Spacing | 1.236 in |
| Lifetime | 3000 Hrs |
| Mounting Type | Chassis Mount |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -25 °C |
| Package / Case | Can - Screw Terminals, Radial |
| Polarization | Polar |
| Size / Dimension Diameter | 3.031 in |
| Tolerance | 20 % |
| Voltage - Rated | 400 V |
