Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | 1693681 | M12 A-code Series |
|---|---|---|
| 1st Connector Gender | Female Sockets | Female Sockets |
| 1st Connector Mounting Type | Free Hanging (In-Line) | Free Hanging (In-Line) |
| 1st Connector Number of Positions | 8 positions | 8 positions |
| 1st Connector Number of Positions Loaded | All | All |
| 1st Connector Orientation | A | A |
| 1st Connector Shell Size - Insert | M16 | M16 |
| 1st Connector Type | Plug, Right Angle | Plug, Right Angle |
| 2nd Connector Type | Wire Leads | Wire Leads |
| Accessory Type | - | Actuator Box |
| Assembly Configuration | Standard | Standard |
| Cable Material | Polyurethane (PUR) | Polyurethane (PUR) |
| Cable Type | Round | Round |
| Color | Black | Green, Black |
| Features | - | Waterproof, Dust Tight |
| Features | - | 4 - 8 RU |
| For Use With/Related Products | - | Circular Connectors |
| Ingress Protection | IP67 - Dust Tight, Waterproof | IP67 - Dust Tight, Waterproof |
| Material | - | Polyamide, Polybutylene Terephthalate (PBT) |
| Shell Size - Insert | - | M12 |
| Shielding | Unshielded | Unshielded |
| Usage | Industrial Environments | Industrial Environments |
M12 A-code Series
Sensor Cables / Actuator Cables SACB6/6-10.0PURSCO 6 SLOT W/OUT LED
| Part | Features | Features | Accessory Type | For Use With/Related Products | Material | Color | Shell Size - Insert | Shielding | 1st Connector Gender | Usage | 1st Connector Orientation | 1st Connector Number of Positions | 2nd Connector Type | Ingress Protection | 1st Connector Type | 1st Connector Number of Positions Loaded | 1st Connector Mounting Type | Assembly Configuration | Cable Material | 1st Connector Shell Size - Insert | Cable Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Phoenix Contact 1662955 | Dust Tight, Waterproof | 8 RU | Actuator Box | Circular Connectors | Polyamide | Green | |||||||||||||||
Phoenix Contact 1517013 | Dust Tight, Waterproof | 6 Fibers | Actuator Box | Circular Connectors | Polybutylene Terephthalate (PBT) | Green | M12 | ||||||||||||||
Phoenix Contact 1452880 | Dust Tight, Waterproof | 6 Fibers | Actuator Box | Circular Connectors | Polybutylene Terephthalate (PBT) | Black | M12 | ||||||||||||||
Phoenix Contact 1693681 | Black | Unshielded | Female Sockets | Industrial Environments | A | 8 positions | Wire Leads | IP67 - Dust Tight, Waterproof | Plug, Right Angle | All | Free Hanging (In-Line) | Standard | Polyurethane (PUR) | M16 | Round | ||||||
Phoenix Contact 1452877 | Dust Tight, Waterproof | 4 Cable Entries | Actuator Box | Circular Connectors | Polybutylene Terephthalate (PBT) | Black | M12 |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
M12 A-code Series
Sensor Cables / Actuator Cables SACB6/6-10.0PURSCO 6 SLOT W/OUT LED
