AT8SDN

Active

AUTONICS

RELAY TIME DELAY 100SEC 5A 250V

Search across all available documentation for this part.

Active

AUTONICS

RELAY TIME DELAY 100SEC 5A 250V

Technical Specifications

Parameters and characteristics for this part

RELAY TIME DELAY 100SEC 5A 250V

Part	Timing Adjustment Method	Voltage - Supply [Max]	Voltage - Supply [Min]	Delay Time [Max]	Delay Time [Min]	Termination Style	Contact Rating @ Voltage	Function
AUTONICS AT8SDN	Hand Dial	240 VDC, 240 VAC	24 V, 100 VAC	100 Sec	0.5 Sec	Plug In, 8 Pin (Octal)	5 A, 250 VAC	Star Delta Controller

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 64.00

General part information

Star Delta Controller Time Delay Relay SPST-NO (1 Form A) 0.5 Sec ~ 100 Sec Delay 5A @ 250VAC Panel Mount

Technical documentation and resources
