CUS400M-48/A
ActiveAC/DC ENCLOSED POWER SUPPLY (PSU), ITE & MEDICAL, 1 OUTPUTS, 250 W, 48 V, 5.21 A
Deep-Dive with AI
Search across all available documentation for this part.
CUS400M-48/A
ActiveAC/DC ENCLOSED POWER SUPPLY (PSU), ITE & MEDICAL, 1 OUTPUTS, 250 W, 48 V, 5.21 A
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | CUS400M-48/A |
|---|---|
| Applications | ITE (Commercial), Medical |
| Approval Agency | CE |
| Current - Output 1 | 5.21 A |
| Features | Universal Input, Remote Sense, Adjustable Output, PFC |
| Minimum Load Required | False |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -20 °C |
| Power (Watts) | 250 W |
| Power (Watts) | 400 W |
| Size / Dimension [x] | 142 mm |
| Size / Dimension [x] | 5.59 in |
| Size / Dimension [y] | 90 mm |
| Size / Dimension [y] | 3.54 in |
| Size / Dimension [z] | 42.5 mm |
| Size / Dimension [z] | 1.67 in |
| Standard Number | 60601-1, 62368-1 |
| Type | Enclosed |
| Voltage - Isolation | 4000 V |
| Voltage - Output 1 | 48 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
CUS400M-48/A
CUS400M-48/A is a 400W CUS400M series AC/DC power supply. The compact CUS400M is packaged in the industry standard 3x5” footprint. The series can deliver 400W with forced air or 250W when convection cooled with a 400W peak power for extended periods of time (minutes). Cooling is also assisted via conduction through the base into the equipment chassis. With Medical & ITE certifications, the units can be used in both Class I & Class II (no ground wire) applications, and meets Class B Conducted and Radiated EMI.
