77-12-3217-02400
ActiveParker Chomerics
RFI FOF GASKET NI/CU ADH
Deep-Dive with AI
Search across all available documentation for this part.
77-12-3217-02400
ActiveParker Chomerics
RFI FOF GASKET NI/CU ADH
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 77-12-3217-02400 |
|---|---|
| Attachment Method | Adhesive |
| Height [z] | 0.039 in |
| Height [z] | 0.99 mm |
| Length [x] | 24 in |
| Length [x] | 609.6 mm |
| Material | Nickel-Copper over Urethane Foam |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -40 °C |
| Shape | Rectangle |
| Shelf Life | 24 Months |
| Shelf Life Start | Date of Manufacture |
| Type | Fabric Over Foam |
| Width [y] | 0.197 in |
| Width [y] | 5 mm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 6.44 | |
| 24 | $ 5.55 | |||
| 120 | $ 4.82 | |||
| 264 | $ 4.60 | |||
| 504 | $ 4.20 | |||
| 1008 | $ 3.65 | |||
| 2520 | $ 3.52 | |||
Description
General part information
77-12-3217-02400
RFI FOF GASKET NI/CU ADH
Documents
Technical documentation and resources
