FN2070B-16-06

Active

TE Connectivity Raychem Cable Protection

LINE FILTER 110V/250VAC 16A CHAS

Search across all available documentation for this part.

Active

TE Connectivity Raychem Cable Protection

LINE FILTER 110V/250VAC 16A CHAS

Technical Specifications

Parameters and characteristics for this part

Specification	FN2070B-16-06

Applications	General Purpose
Approval Agency	CSA, ENEC, UR
Configuration	Two Stage
Current	16 A
Filter Type	Single Phase
Frequency - Operating	400 Hz
Inductance	2.8 mH
Mounting Type	Chassis Mount
Operating Temperature [custom]	100 °C, -25 °C
Termination Style	Quick Connect
Voltage - Rated AC	250 V, 110 V

Part	Inductance	Voltage - Rated AC	Termination Style	Frequency - Operating	Operating Temperature [custom]	Filter Type	Current	Approval Agency	Mounting Type	Configuration	Applications
TE Connectivity Raychem Cable Protection FN2070B-3-07	9.8 mH	110 V 250 V	Wire Leads	400 Hz	-25 °C 100 °C	Single Phase	3 A	CSA ENEC UR	Chassis Mount	Two Stage	General Purpose
TE Connectivity Raychem Cable Protection FN2070B-6-06	7.8 mH	110 V 250 V	Quick Connect	400 Hz	-25 °C 100 °C	Single Phase	6 A	CSA ENEC UR	Chassis Mount	Two Stage	General Purpose
TE Connectivity Raychem Cable Protection FN2070B-3-06	9.8 mH	110 V 250 V	Quick Connect	400 Hz	-25 °C 100 °C	Single Phase	3 A	CSA ENEC UR	Chassis Mount	Two Stage	General Purpose
TE Connectivity Raychem Cable Protection FN2070B-16-06	2.8 mH	110 V 250 V	Quick Connect	400 Hz	-25 °C 100 °C	Single Phase	16 A	CSA ENEC UR	Chassis Mount	Two Stage	General Purpose
TE Connectivity Raychem Cable Protection FN2070B-1-06	22 mH	110 V 250 V	Quick Connect	400 Hz	-25 °C 100 °C	Single Phase	1 A	CSA ENEC UR	Chassis Mount	Two Stage	General Purpose

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Single Phase EMC/EMI Line Filter 16 A 110V, 250V DC ~ 400Hz Two Stage Quick Connect
