C016 20H003 804 12
ActiveAmphenol Tuchel Industrial
CONN PLUG MALE 4POS GOLD SCREW
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
C016 20H003 804 12
ActiveAmphenol Tuchel Industrial
CONN PLUG MALE 4POS GOLD SCREW
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | C016 20H003 804 12 | C016 20H003 Series |
|---|---|---|
| Connector Type | Plug, Male Pins | Plug, Male Pins |
| Contact Finish - Mating | Gold | Gold |
| Current Rating (Amps) | 16 A | 16 A |
| Features | - | Cable Clamp, Strain Relief |
| Ingress Protection | IP67, IP65 | IP67, IP65 |
| Mounting Type | Free Hanging (In-Line) | Free Hanging (In-Line) |
| Number of Positions | 4 | 4 |
| Operating Temperature [Max] | 100 °C | 100 °C |
| Operating Temperature [Min] | -40 °C | -40 °C |
| Orientation | Keyed | Keyed |
| Primary Material | Plastic | Plastic |
| Termination | Screw | Screw |
| Voltage Rating | 400 V | 400 V |
C016 20H003 Series
CONN PLUG MALE 4POS GOLD SCREW
| Part | Number of Positions | Operating Temperature [Max] | Operating Temperature [Min] | Current Rating (Amps) | Mounting Type | Primary Material | Ingress Protection | Termination | Contact Finish - Mating | Orientation | Voltage Rating | Connector Type | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Amphenol Tuchel Industrial C016 20H003 804 12 | 4 | 100 °C | -40 °C | 16 A | Free Hanging (In-Line) | Plastic | IP65, IP67 | Screw | Gold | Keyed | 400 V | Male Pins, Plug | |
Amphenol Tuchel Industrial C016 20H003 800 11 | 4 | 100 °C | -40 °C | 16 A | Free Hanging (In-Line) | Plastic | IP65, IP67 | Screw | Keyed | 400 V | Male Pins, Plug | Cable Clamp | |
Amphenol Tuchel Industrial C016 20H003 210 10 | 4 | 100 °C | -40 °C | 16 A | Free Hanging (In-Line) | Plastic | IP65, IP67 | Screw | Gold | Keyed | 400 V | Male Pins, Plug | Cable Clamp, Strain Relief |
Amphenol Tuchel Industrial C016 20H003 800 17 | 4 | 100 °C | -40 °C | 16 A | Free Hanging (In-Line) | Plastic | IP65, IP67 | Screw | Keyed | 400 V | Male Pins, Plug | Cable Clamp | |
Amphenol Tuchel Industrial C016 20H003 200 12 | 4 | 100 °C | -40 °C | 16 A | Free Hanging (In-Line) | Plastic | IP65, IP67 | Screw | Gold | Keyed | 400 V | Male Pins, Plug | Cable Clamp |
Amphenol Tuchel Industrial C016 20H003 210 12 | 4 | 100 °C | -40 °C | 16 A | Free Hanging (In-Line) | Plastic | IP65, IP67 | Screw | Gold | Keyed | 400 V | Male Pins, Plug | Cable Clamp, Strain Relief |
Amphenol Tuchel Industrial C016 20H003 800 18 | 4 | 100 °C | -40 °C | 16 A | Free Hanging (In-Line) | Plastic | IP65, IP67 | Screw | Keyed | 400 V | Male Pins, Plug | Cable Clamp |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 250 | $ 10.76 | |
Description
General part information
C016 20H003 Series
4 Position Circular Connector Plug, Male Pins Screw
Documents
Technical documentation and resources
