PAGA-3114
ObsoleteZF Electronics
SWITCH THUMB HEX 0.1A 50V
PAGA-3114
ObsoleteZF Electronics
SWITCH THUMB HEX 0.1A 50V
Description
General part information
PAGA-3114
Thumbwheel Switch Hexadecimal 0.1A @ 50VAC/DC Panel Mount, Snap-In
Technical Specifications
Parameters and characteristics for this part
| Specification | PAGA-3114 |
|---|---|
| Actuator Type | Pushwheel |
| Color | Black |
| Contact Finish | Gold Alloy |
| Contact Rating (Current) | 100 mA |
| Depth Behind Flange | 24 mm |
| Display Characters - Height | 0.071 in |
| End Caps | Included |
| Features | Pen-Push Actuator |
| Housing Material | PPO, Polyphenylene Oxide |
| Mounting Type | Panel Mount, Snap-In |
| Number of Sections | 1 |
| Operating Temperature (Max) | 80 °C |
| Operating Temperature (Min) | -20 °C |
| Output Code | Hexadecimal |
| Panel Cutout Length | 14.3 mm |
| Panel Cutout Shape | Rectangular |
| Panel Cutout Width | 10.92 mm |
| Read Out (Max) | 15 |
| Read Out (Min) | 0 |
| Section Width | 0.3 in |
| Termination Style | Card Edge, Solder Pad |
| Voltage Rating | 50VAC, DC |
