AZ943-1AH-12DE

Active

American Zettler

RELAY GEN PURPOSE SPST 15A 12V

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

AZ943-1AH-12DE

Active

American Zettler

RELAY GEN PURPOSE SPST 15A 12V

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tube	1	$ 0.80
		10	$ 0.75
		25	$ 0.67
		50	$ 0.63
		100	$ 0.60
		250	$ 0.53
		500	$ 0.50
		1000	$ 0.47
		5000	$ 0.45

Description

General part information

AZ943-1A Series

General Purpose Relay SPST-NO (1 Form A) 12VDC Coil Through Hole

Documents

Technical documentation and resources

Datasheet

Specification	AZ943-1AH-12DE	AZ943-1A Series

Approval Agency	TUV, VDE, UL, cUR	TUV, VDE, UL, cUR
Coil Current	30 mA	7.5 - 71.4 mA
Coil Insulation	Class B	Class B, Class F
Coil Resistance	400 Ohms	1.6 - 900 kOhms
Coil Type	Non Latching	Non Latching
Coil Voltage	12 VDC	5 - 48 VDC
Contact Form	SPST-NO (1 Form A)	SPST-NO (1 Form A)
Contact Material	Silver Tin Oxide (AgSnO)	Silver Tin Oxide (AgSnO), Gold (Au)
Contact Rating (Current)	15 A	15 A
Load - Max Switching	2770 VA, 300 W	300 - 2770 VA
Mounting Type	Through Hole	Through Hole
Must Operate Voltage	9 VDC	3.8 - 36 VDC
Must Release Voltage	1.2 VDC	0.5 - 4.8 VDC
Operate Time	10 ms	10 ms
Operating Temperature [Max]	90 °C	90 - 110 °C
Operating Temperature [Min]	-40 °C	-40 °C
Relay Type	General Purpose	General Purpose
Release Time	5 ms	5 ms
Seal Rating	Sealed - Fully	Sealed - Fully, Sealed - Flux Protection
Switching Voltage	277 VAC, 30 VDC	30 - 277 VAC
Termination Style	PC Pin	PC Pin

Part

Contact Rating (Current)

Coil Current

Switching Voltage

Load - Max Switching

Must Operate Voltage

Approval Agency

Must Release Voltage

Contact Material

Termination Style

Operating Temperature [Max]

Operating Temperature [Min]

Release Time

Coil Insulation

Contact Form

Coil Resistance

Seal Rating

Mounting Type

Operate Time

Relay Type

Coil Voltage

Coil Type

American Zettler

AZ943-1AH-24DE

15 A

15 mA

30 VDC, 277 VAC

300 W, 2770 VA

18 VDC

cUR, TUV, UL, VDE

2.4 VDC

Silver Tin Oxide (AgSnO)

PC Pin

90 °C

-40 °C

5 ms

Class B

SPST-NO (1 Form A)

1.6 kOhms

Sealed - Fully

Through Hole

10 ms

General Purpose

24 VDC

Non Latching

American Zettler

AZ943-1AH-5D

15 A

71.4 mA

30 VDC, 277 VAC

300 W, 2770 VA

3.8 VDC

cUR, TUV, UL, VDE

0.5 VDC

Silver Tin Oxide (AgSnO)

PC Pin

90 °C

-40 °C

5 ms

Class B

SPST-NO (1 Form A)

70 Ohms

Sealed - Flux Protection

Through Hole

10 ms

General Purpose

5 VDC

Non Latching

American Zettler

AZ943-1AH-36DE

15 A

30 VDC, 277 VAC

300 W, 2770 VA

cUR, TUV, UL, VDE

3.6 VDC

Silver Tin Oxide (AgSnO)

PC Pin

90 °C

-40 °C

5 ms

Class B

SPST-NO (1 Form A)

Sealed - Fully

Through Hole

10 ms

General Purpose

36 VDC

Non Latching

American Zettler

AZ943-1AH-5DEG

15 A

71.4 mA

30 VDC, 277 VAC

300 W, 2770 VA

3.8 VDC

cUR, TUV, UL, VDE

0.5 VDC

Gold (Au), Silver Tin Oxide (AgSnO)

PC Pin

90 °C

-40 °C

5 ms

Class B

SPST-NO (1 Form A)

70 Ohms

Sealed - Fully

Through Hole

10 ms

General Purpose

5 VDC

Non Latching

American Zettler

AZ943-1AH-9DE

15 A

40 mA

30 VDC, 277 VAC

300 W, 2770 VA

6.8 VDC

cUR, TUV, UL, VDE

0.9 VDC

Silver Tin Oxide (AgSnO)

PC Pin

90 °C

-40 °C

5 ms

Class B

SPST-NO (1 Form A)

225 Ohms

Sealed - Fully

Through Hole

10 ms

General Purpose

9 VDC

Non Latching

American Zettler

AZ943-1AH-24D

15 A

15 mA

30 VDC, 277 VAC

300 W, 2770 VA

18 VDC

cUR, TUV, UL, VDE

2.4 VDC

Silver Tin Oxide (AgSnO)

PC Pin

90 °C

-40 °C

5 ms

Class B

SPST-NO (1 Form A)

1.6 kOhms

Sealed - Flux Protection

Through Hole

10 ms

General Purpose

24 VDC

Non Latching

American Zettler

AZ943-1AH-6DE

15 A

60 mA

30 VDC, 277 VAC

300 W, 2770 VA

4.5 VDC

cUR, TUV, UL, VDE

0.6 VDC

Silver Tin Oxide (AgSnO)

PC Pin

90 °C

-40 °C

5 ms

Class B

SPST-NO (1 Form A)

100 Ohms

Sealed - Fully

Through Hole

10 ms

General Purpose

Non Latching

American Zettler

AZ943-1AH-6D

15 A

60 mA

30 VDC, 277 VAC

300 W, 2770 VA

4.5 VDC

cUR, TUV, UL, VDE

0.6 VDC

Silver Tin Oxide (AgSnO)

PC Pin

90 °C

-40 °C

5 ms

Class B

SPST-NO (1 Form A)

100 Ohms

Sealed - Flux Protection

Through Hole

10 ms

General Purpose

Non Latching

American Zettler

AZ943-1AH-24DEG

15 A

15 mA

30 VDC, 277 VAC

300 W, 2770 VA

18 VDC

cUR, TUV, UL, VDE

2.4 VDC

Gold (Au), Silver Tin Oxide (AgSnO)

PC Pin

90 °C

-40 °C

5 ms

Class B

SPST-NO (1 Form A)

1.6 kOhms

Sealed - Fully

Through Hole

10 ms

General Purpose

24 VDC

Non Latching

American Zettler

AZ943-1AH-15DF

15 A

30 VDC, 277 VAC

300 W, 2770 VA

cUR, TUV, UL, VDE

1.5 VDC

Silver Tin Oxide (AgSnO)

PC Pin

110 °C

-40 °C

5 ms

Class F

SPST-NO (1 Form A)

Sealed - Flux Protection

Through Hole

10 ms

General Purpose

15 VDC

Non Latching

Part	Contact Rating (Current)	Coil Current	Switching Voltage	Load - Max Switching	Must Operate Voltage	Approval Agency	Must Release Voltage	Contact Material	Termination Style	Operating Temperature [Max]	Operating Temperature [Min]	Release Time	Coil Insulation	Contact Form	Coil Resistance	Seal Rating	Mounting Type	Operate Time	Relay Type	Coil Voltage	Coil Type
American Zettler AZ943-1AH-24DE	15 A	15 mA	30 VDC, 277 VAC	300 W, 2770 VA	18 VDC	cUR, TUV, UL, VDE	2.4 VDC	Silver Tin Oxide (AgSnO)	PC Pin	90 °C	-40 °C	5 ms	Class B	SPST-NO (1 Form A)	1.6 kOhms	Sealed - Fully	Through Hole	10 ms	General Purpose	24 VDC	Non Latching
American Zettler AZ943-1AH-5D	15 A	71.4 mA	30 VDC, 277 VAC	300 W, 2770 VA	3.8 VDC	cUR, TUV, UL, VDE	0.5 VDC	Silver Tin Oxide (AgSnO)	PC Pin	90 °C	-40 °C	5 ms	Class B	SPST-NO (1 Form A)	70 Ohms	Sealed - Flux Protection	Through Hole	10 ms	General Purpose	5 VDC	Non Latching
American Zettler AZ943-1AH-36DE	15 A		30 VDC, 277 VAC	300 W, 2770 VA		cUR, TUV, UL, VDE	3.6 VDC	Silver Tin Oxide (AgSnO)	PC Pin	90 °C	-40 °C	5 ms	Class B	SPST-NO (1 Form A)		Sealed - Fully	Through Hole	10 ms	General Purpose	36 VDC	Non Latching
American Zettler AZ943-1AH-5DEG	15 A	71.4 mA	30 VDC, 277 VAC	300 W, 2770 VA	3.8 VDC	cUR, TUV, UL, VDE	0.5 VDC	Gold (Au), Silver Tin Oxide (AgSnO)	PC Pin	90 °C	-40 °C	5 ms	Class B	SPST-NO (1 Form A)	70 Ohms	Sealed - Fully	Through Hole	10 ms	General Purpose	5 VDC	Non Latching
American Zettler AZ943-1AH-9DE	15 A	40 mA	30 VDC, 277 VAC	300 W, 2770 VA	6.8 VDC	cUR, TUV, UL, VDE	0.9 VDC	Silver Tin Oxide (AgSnO)	PC Pin	90 °C	-40 °C	5 ms	Class B	SPST-NO (1 Form A)	225 Ohms	Sealed - Fully	Through Hole	10 ms	General Purpose	9 VDC	Non Latching
American Zettler AZ943-1AH-24D	15 A	15 mA	30 VDC, 277 VAC	300 W, 2770 VA	18 VDC	cUR, TUV, UL, VDE	2.4 VDC	Silver Tin Oxide (AgSnO)	PC Pin	90 °C	-40 °C	5 ms	Class B	SPST-NO (1 Form A)	1.6 kOhms	Sealed - Flux Protection	Through Hole	10 ms	General Purpose	24 VDC	Non Latching
American Zettler AZ943-1AH-6DE	15 A	60 mA	30 VDC, 277 VAC	300 W, 2770 VA	4.5 VDC	cUR, TUV, UL, VDE	0.6 VDC	Silver Tin Oxide (AgSnO)	PC Pin	90 °C	-40 °C	5 ms	Class B	SPST-NO (1 Form A)	100 Ohms	Sealed - Fully	Through Hole	10 ms	General Purpose		Non Latching
American Zettler AZ943-1AH-6D	15 A	60 mA	30 VDC, 277 VAC	300 W, 2770 VA	4.5 VDC	cUR, TUV, UL, VDE	0.6 VDC	Silver Tin Oxide (AgSnO)	PC Pin	90 °C	-40 °C	5 ms	Class B	SPST-NO (1 Form A)	100 Ohms	Sealed - Flux Protection	Through Hole	10 ms	General Purpose		Non Latching
American Zettler AZ943-1AH-24DEG	15 A	15 mA	30 VDC, 277 VAC	300 W, 2770 VA	18 VDC	cUR, TUV, UL, VDE	2.4 VDC	Gold (Au), Silver Tin Oxide (AgSnO)	PC Pin	90 °C	-40 °C	5 ms	Class B	SPST-NO (1 Form A)	1.6 kOhms	Sealed - Fully	Through Hole	10 ms	General Purpose	24 VDC	Non Latching
American Zettler AZ943-1AH-15DF	15 A		30 VDC, 277 VAC	300 W, 2770 VA		cUR, TUV, UL, VDE	1.5 VDC	Silver Tin Oxide (AgSnO)	PC Pin	110 °C	-40 °C	5 ms	Class F	SPST-NO (1 Form A)		Sealed - Flux Protection	Through Hole	10 ms	General Purpose	15 VDC	Non Latching
