D38999/20LJ19PAL
ActiveCorsair
D38999 SER III RECEPTACLE
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
D38999/20LJ19PAL
ActiveCorsair
D38999 SER III RECEPTACLE
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | D38999/20LJ19PAL | D38999/20LJ Series |
|---|---|---|
| - | - | |
| Connector Type | Receptacle Housing | Receptacle Housing |
| Contact Type | Crimp | Crimp |
| Housing Color | Silver | Silver |
| Includes | 1 pc - 1 Insert Shell | 1 pc - 1 Insert Shell |
| Ingress Protection | Waterproof | Waterproof |
| Insert Material | Thermoplastic | Thermoplastic |
| Material Flammability Rating | UL94 V-0 | UL94 V-0 |
| Mounting Feature | Flange | Flange |
| Note | Contacts Not Included | Contacts Not Included |
| Number of Positions | 19 | 19 - 61 |
| Operating Temperature [Max] | 200 °C | 200 °C |
| Operating Temperature [Min] | -65 ░C | -65 ░C |
| Orientation | N | B, N |
| Primary Material | Metal | Metal |
| Shell Size, MIL | J | J |
| Type | For Female Sockets | For Female Sockets |
D38999/20LJ Series
D38999 SER III RECEPTACLE
| Part | Type | Shell Size, MIL | Primary Material | Connector Type | Orientation | Mounting Feature | Contact Type | Number of Positions | Note | Material Flammability Rating | Ingress Protection | Insert Material | Includes | Operating Temperature [Min] | Operating Temperature [Max] | Housing Color |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Corsair D38999/20LJ61SBL | For Female Sockets | J | Metal | Receptacle Housing | B | Flange | Crimp | 61 | Contacts Not Included | |||||||
Corsair D38999/20LJ29PBL | ||||||||||||||||
Corsair D38999/20LJ19PAL | For Female Sockets | J | Metal | Receptacle Housing | N | Flange | Crimp | 19 | Contacts Not Included | UL94 V-0 | Waterproof | Thermoplastic | 1 pc - 1 Insert Shell | -65 ░C | 200 °C | Silver |
Corsair D38999/20LJ29PA | ||||||||||||||||
Corsair D38999/20LJ24PA | ||||||||||||||||
Corsair D38999/20LJ24SB | ||||||||||||||||
Corsair D38999/20LJ24SA | ||||||||||||||||
Corsair D38999/20LJ24SBL | ||||||||||||||||
Corsair D38999/20LJ24SAL | ||||||||||||||||
Corsair D38999/20LJ29PB |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bag | 1 | $ 100.66 | |
| 10 | $ 99.01 | |||
| 25 | $ 95.86 | |||
| 50 | $ 92.92 | |||
| 100 | $ 87.54 | |||
| 250 | $ 82.74 | |||
| 500 | $ 80.53 | |||
| 1000 | $ 78.43 | |||
Description
General part information
D38999/20LJ Series
19 Position Circular Connector Receptacle Housing Panel Mount
