Description
General part information
C317C331MDR5HA7301
330 pF ±20% 1000V (1kV) Ceramic Capacitor X7R Radial
Technical Specifications
Parameters and characteristics for this part
| Specification | C317C331MDR5HA7301 |
|---|---|
| Applications | Bypass, Decoupling |
| Capacitance | 330 pF |
| Features | High Voltage |
| Height - Seated (Max) | 0.2 in |
| Lead Spacing | 0.2 in |
| Lead Style | Straight |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Radial |
| Size / Dimension Length | 0.15 in |
| Size / Dimension Width | 0.124 in |
| Temperature Coefficient | X7R |
| Tolerance | 20 % |
| Voltage - Rated | 1000 V |
