241-3-120
ActiveSignal Transformer
POWER TRANSFORMER 2500VRMS 2.4VA 5 TERMINAL QUICK CONNECT/SOLDER LUG FLANGE MOUNT
241-3-120
ActiveSignal Transformer
POWER TRANSFORMER 2500VRMS 2.4VA 5 TERMINAL QUICK CONNECT/SOLDER LUG FLANGE MOUNT
Description
General part information
241-3-120
POWER TRANSFORMER 2500VRMS 2.4VA 5 TERMINAL QUICK CONNECT/SOLDER LUG FLANGE MOUNT
Technical Specifications
Parameters and characteristics for this part
| Specification | 241-3-120 |
|---|---|
| Center Tap | Yes |
| Current - Output (Max) | 20 mA |
| Height - Seated (Max) | 31.2 mm |
| Mounting Type | Chassis Mount |
| Power - Max | 2.4 W |
| Primary Winding(s) | Single |
| Secondary Winding(s) | Single |
| Size / Dimension Length | 52.6 mm |
| Size / Dimension Width | 29.6 mm |
| Termination Style | Solder, Quick Connect |
| Type | Laminated Core |
| Voltage - Isolation | 2500 Vrms |
| Voltage - Primary | 115 V |
| Voltage - Secondary (Full Load) | 120 V |
| Weight | 0.25 lbs |
