1791868
ActiveWIRE-TO-BOARD TERMINAL BLOCK, 2.54 MM, 1 POSITIONS, 26 AWG, 20 AWG, 0.5 MM², PUSH IN
1791868
ActiveWIRE-TO-BOARD TERMINAL BLOCK, 2.54 MM, 1 POSITIONS, 26 AWG, 20 AWG, 0.5 MM², PUSH IN
Description
General part information
1791868
The 1791868 is a 1-position green end termination block to be used with Phoenix 1791826 PCB terminal block(s). This FFKDSA1/H-5,08 terminal block has push-in spring connection and fully developed contact geometries and surfaces. It has push-in direct plug-in technology for solid or stranded conductors with ferrules. When connecting stranded conductors without ferrules, the terminal point is opened using an orange opening lever. It accepts 26 to 20AWG wire range.
Technical Specifications
Parameters and characteristics for this part
| Specification | 1791868 |
|---|---|
| Color | Green |
| Current | 6 A |
| Features | Interlocking (Side), Lever Actuated |
| Housing Material | Nylon, Polyamide, PA |
| Mating Orientation | Horizontal with Board |
| Mounting Type | Through Hole |
| Number of Levels | 1 |
| Positions Per Level | 1 |
| Voltage | 150 V |
| Wire Gauge (AWG) (Max) | 26 AWG |
| Wire Gauge (AWG) (Min) | 19.5 AWG |
| Wire Termination | Spring Cage, Screwless, Tension Clamp |
