Z60-7-LAN-L-U

Active

TDK-LAMBDA

BENCH POWER SUPPLY, ADJUSTABLE, 1 OUTPUT, 0 V, 60 V, 0 A, 7 A

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsUser Manual EN Declaration of Conformity EN +4

Z60-7-LAN-L-U

Active

TDK-LAMBDA

BENCH POWER SUPPLY, ADJUSTABLE, 1 OUTPUT, 0 V, 60 V, 0 A, 7 A

Deep-Dive with AI

DocumentsUser Manual EN Declaration of Conformity EN +4

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	Z60-7-LAN-L-U

Accuracy - Voltmeter; Ammeter	0.5% + 1 count
Current - Output [Max]	7 A
Current - Output [Min]	0 A
Current Regulation - Line	2 mA
Current Regulation - Load	5 mA
Display Type	Digital
Features	RS485, Programmable, LAN, RS232, USB Interface
Number of Characters	4
Number of Outputs	1
Power (Watts)	420 W
Ripple	5 mV
Size / Dimension [x]	13.78 in
Size / Dimension [x]	350 mm
Size / Dimension [y]	4.134 "
Size / Dimension [y]	105 mm
Size / Dimension [z]	3.268 in
Size / Dimension [z]	83 mm
Type	Bench (AC to DC)
Voltage - Output [Max]	60 VDC
Voltage - Output [Min]	0 VDC
Voltage - Supply [Max]	265 VAC
Voltage - Supply [Min]	85 VAC
Voltage Regulation - Load	2 mV
Weight	2.4 kg
Weight	5.3 lbs

Z60 Series

Part	Current Regulation - Load	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [z]	Ripple	Voltage - Supply [Max]	Voltage - Supply [Min]	Weight	Weight	Display Type	Voltage - Output [Max]	Accuracy - Voltmeter; Ammeter	Current Regulation - Line	Number of Characters	Features	Power (Watts)	Number of Outputs	Type	Current - Output [Max]	Voltage Regulation - Load	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]
TDK-LAMBDA Z60-7-L-U	5 mA	13.78 in	4.134 "	350 mm	105 mm	3.268 in	83 mm	5 mV	265 VAC	85 VAC	2.4 kg	5.3 lbs	Digital	60 VDC	0.5% + 1 count	2 mA	4	Programmable RS232 RS485 USB Interface	420 W	1	Bench (AC to DC)	7 A	2 mV
TDK-LAMBDA Z60-14-IS420-U	5 mA	13.78 in	4.134 "	350 mm	105 mm	3.268 in	83 mm	6.25 mV	265 VAC	85 VAC	2.4 kg	5.3 lbs	Digital	60 VDC	0.5% + 1 count	2 mA	4	Programmable RS232 RS485 USB Interface	840 W	1	Bench (AC to DC)	14 A	2 mV
TDK-LAMBDA Z60-7-IS420-U	5 mA	13.78 in	4.134 "	350 mm	105 mm	3.268 in	83 mm	5 mV	265 VAC	85 VAC	2.4 kg	5.3 lbs	Digital	60 VDC	0.5% + 1 count	2 mA	4	Programmable RS232 RS485 USB Interface	420 W	1	Bench (AC to DC)	7 A	2 mV
TDK-LAMBDA Z60-3.5-IS420-U	5 mA	13.78 in	4.134 "	350 mm	105 mm	3.268 in	83 mm	5 mV	265 VAC	85 VAC	2.4 kg	5.3 lbs	Digital	60 VDC	0.5% + 1 count	2 mA	4	Programmable RS232 RS485 USB Interface	210 W	1	Bench (AC to DC)	3.5 A	2 mV
TDK-LAMBDA Z60-3.5-LAN-L-U	5 mA	13.78 in	4.134 "	350 mm	105 mm	3.268 in	83 mm	5 mV	265 VAC	85 VAC	2.4 kg	5.3 lbs	Digital	60 VDC	0.5% + 1 count	2 mA	4	LAN Programmable RS232 RS485 USB Interface	210 W	1	Bench (AC to DC)	3.5 A	2 mV
TDK-LAMBDA Z60-3.5-IEEE-U	5 mA	13.78 in	4.134 "	350 mm	105 mm	3.268 in	83 mm	5 mV	265 VAC	85 VAC	2.4 kg	5.3 lbs	Digital	60 VDC	0.5% + 1 count	2 mA	4	GPIB Programmable RS232 RS485 USB Interface	210 W	1	Bench (AC to DC)	3.5 A	2 mV
TDK-LAMBDA Z60-7-LAN-U	5 mA			13.78 "	2.756 "		3.268 "	5 mV	265 VAC	85 VAC	1.9 kg	4.2 lbs	Digital	60 VDC	0.5% + 1 count	2 mA	4	LAN Programmable RS232 RS485 USB Interface	420 W	1	Bench (AC to DC)	7 A	2 mV	83 mm	70 mm	350 mm
TDK-LAMBDA Z60-10-U	5 mA			13.78 "	2.756 "		3.268 "	6.25 mV	265 VAC	85 VAC	1.9 kg	4.2 lbs	Digital	60 VDC	0.5% + 1 count	2 mA	4	Programmable RS232 RS485 USB Interface	600 W	1	Bench (AC to DC)	10 A	2 mV	83 mm	70 mm	350 mm
TDK-LAMBDA Z60-14-L-U	5 mA	13.78 in	4.134 "	350 mm	105 mm	3.268 in	83 mm	6.25 mV	265 VAC	85 VAC	2.4 kg	5.3 lbs	Digital	60 VDC	0.5% + 1 count	2 mA	4	Programmable RS232 RS485 USB Interface	840 W	1	Bench (AC to DC)	14 A	2 mV
TDK-LAMBDA Z60-3.5-U	5 mA			13.78 "	2.756 "		3.268 "	5 mV	265 VAC	85 VAC	1.9 kg	4.2 lbs	Digital	60 VDC	0.5% + 1 count	2 mA	4	Programmable RS232 RS485 USB Interface	210 W	1	Bench (AC to DC)	3.5 A	2 mV	83 mm	70 mm	350 mm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 2502.63
Newark	Each	1	$ 2502.62
		10	$ 2194.46
		25	$ 2058.76
		50	$ 2058.76

Description

General part information

Z60 Series

0 ~ 60VDC Output Bench (AC to DC) Power Supply Digital 0 ~ 7A Output 420W Features LAN, Programmable, RS232, RS485 and USB Interface
