218-106/000-604
ActiveWAGO Corporation
THR PCB TERMINAL BLOCK; LOCKING
218-106/000-604
ActiveWAGO Corporation
THR PCB TERMINAL BLOCK; LOCKING
Description
General part information
218-106/000-604
6 Position Wire to Board Terminal Block 40° (130°) Angle with Board 0.098" (2.50mm) Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | 218-106/000-604 |
|---|---|
| Clamp Material | Steel |
| Clamp Plating | Nickel Plated |
| Color | Black |
| Contact Material | Electrolytic Copper |
| Housing Material | PA46, Polyamide, Nylon 4/6 |
| Mating Orientation (Angle) | 40 ° |
| Mating Orientation (Angle) (Alternate) | 130 ° |
| Mating Orientation (Description) | Angle with Board |
| Mounting Type | Through Hole |
| Number of Levels | 1 |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -60 °C |
| Pitch | 0.098 in |
| Plating | Tin Plated |
| Positions Per Level | 6 |
| Wire Gauge (AWG) (Max) | 28 AWG |
| Wire Gauge (AWG) (Min) | 19.5 AWG |
| Wire Termination | Spring Cage, Screwless, Tension Clamp |
