Description

General part information

MMP6S47K-F

0.047 µF Film Capacitor 250V 630V Polyester, Metallized Axial

Technical Specifications

Parameters and characteristics for this part

SpecificationMMP6S47K-F
ApplicationsGeneral Purpose
Capacitance47 nF
Dielectric MaterialPolyester, Metallized
FeaturesLong Life
Mounting TypeThrough Hole
Operating Temperature (Max)125 °C
Operating Temperature (Min)-55 °C
Package / CaseAxial
Size / Dimension Length0.906 in
Size / Dimension Thickness0.236 in
Size / Dimension Width0.394 in
TerminationPC Pins
Tolerance10 %
Voltage Rating - AC250 V
Voltage Rating - DC630 V

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Sign in to see pricing

Create a free account to access distributor pricing data.

Sign up — freeLog in

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

MMP6S47K-F | Datasheet
