19M433J
ActiveGowanda Electronics
MOLDED UNSHIELDED RF COILS AXL
19M433J
ActiveGowanda Electronics
MOLDED UNSHIELDED RF COILS AXL
Description
General part information
19M433J
430 µH Unshielded Molded Inductor 97 mA 10.6Ohm Max Axial
Technical Specifications
Parameters and characteristics for this part
| Specification | 19M433J |
|---|---|
| Current Rating | 97 mA |
| DC Resistance (DCR) (Max) | 10.6 Ohm |
| Frequency - Self Resonant | 4.3 MHz |
| Inductance | 430 µH |
| Inductance Frequency - Test | 790 kHz |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Axial |
| Package Name | Axial |
| Q | 65 |
| Shielding | Unshielded |
| Size / Dimension Diameter | 0.19 in |
| Size / Dimension Length | 0.44 in |
| Tolerance | 5 % |
| Type | Molded |
