CTCDRH62BF-100M
ActiveCentral Technologies
10UH SMD SHIELDED POWR INDUCTOR
CTCDRH62BF-100M
ActiveCentral Technologies
10UH SMD SHIELDED POWR INDUCTOR
Description
General part information
CTCDRH62BF-100M
10 µH Shielded Inductor 150mOhm Max Nonstandard
Technical Specifications
Parameters and characteristics for this part
| Specification | CTCDRH62BF-100M |
|---|---|
| Current - Saturation (Isat) | 1.1 A |
| DC Resistance (DCR) (Max) | 150 mOhm |
| Height - Seated (Max) | 0.118 in |
| Inductance | 10 µH |
| Inductance Frequency - Test | 1 kHz |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Nonstandard |
| Shielding | Shielded |
| Size / Dimension Length | 0.26 in |
| Size / Dimension Width | 0.244 in |
| Tolerance | 20 % |
