CF1/4CT52R822J
ActiveKOA Speer Electronics, Inc.
RES 8.2K OHM 5% 1/4W AXIAL
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
CF1/4CT52R822J
ActiveKOA Speer Electronics, Inc.
RES 8.2K OHM 5% 1/4W AXIAL
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | CF1/4CT52R822J |
|---|---|
| Composition | Carbon Film |
| Number of Terminations | 2 |
| Operating Temperature [Max] | 155 °C |
| Operating Temperature [Min] | -55 °C |
| Package / Case | Axial |
| Power (Watts) | 0.25 W |
| Power (Watts) | 250 mW |
| Resistance | 8.2 kOhms |
| Size / Dimension [diameter] | 0.091 " |
| Size / Dimension [diameter] | 2.3 mm |
| Size / Dimension [z] | 6.1 mm |
| Size / Dimension [z] | 0.24 " |
| Supplier Device Package | Axial |
| Temperature Coefficient [Max] | 350 ppm/°C |
| Temperature Coefficient [Min] | -450 ppm/°C |
| Tolerance | 5 % |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 0.10 | |
| 10 | $ 0.09 | |||
| 25 | $ 0.06 | |||
| 50 | $ 0.05 | |||
| 100 | $ 0.03 | |||
| 250 | $ 0.03 | |||
| 500 | $ 0.02 | |||
| 1000 | $ 0.02 | |||
| Tape & Reel (TR) | 5000 | $ 0.01 | ||
| 10000 | $ 0.01 | |||
| 25000 | $ 0.01 | |||
| 50000 | $ 0.01 | |||
| 125000 | $ 0.01 | |||
Description
General part information
CF1/4CT52R822J
8.2 kOhms ±5% 0.25W, 1/4W Through Hole Resistor Axial Carbon Film
