ACTT2W-800ETNF

Active

WeEn Semiconductors

AC THYRISTOR TRIAC POWER SWITCH

Search across all available documentation for this part.

Active

WeEn Semiconductors

AC THYRISTOR TRIAC POWER SWITCH

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	ACTT2W-800ETNF	ACTT2 Series

Configuration	Single	Single
Current - Gate Trigger (Igt) (Max) [Max]	10 mA	10 mA
Current - Hold (Ih) (Max) [Max]	10 mA	10 - 25 mA
Current - Non Rep. Surge 50, 60Hz (Itsm)	20 A, 18 A	14 - 20 A
Current - On State (It (RMS)) (Max) [Max]	2 A	2 A
Mounting Type	Surface Mount	Surface Mount, Through Hole
Operating Temperature	150 °C	125 - 150 °C
Package / Case	TO-261AA, TO-261-4	TO-261AA, TO-261-4, TO-220-3 Full Pack, Isolated Tab, SC-63, DPAK (2 Leads + Tab), TO-252-3
Supplier Device Package	SC-73	SC-73, TO-220F, DPAK
Triac Type	Standard	Standard, Logic - Sensitive Gate
Voltage - Gate Trigger (Vgt) (Max) [Max]	1 V	1 - 2 V
Voltage - Off State	800 V	800 V

AC THYRISTOR TRIAC POWER SWITCH

Part	Mounting Type	Operating Temperature	Configuration	Current - Hold (Ih) (Max) [Max]	Triac Type	Current - On State (It (RMS)) (Max) [Max]	Voltage - Off State	Supplier Device Package	Voltage - Gate Trigger (Vgt) (Max) [Max]	Current - Non Rep. Surge 50, 60Hz (Itsm)	Package / Case	Current - Gate Trigger (Igt) (Max) [Max]
WeEn Semiconductors ACTT2W-800ETNF	Surface Mount	150 °C	Single	10 mA	Standard	2 A	800 V	SC-73	1 V	18 A, 20 A	TO-261-4, TO-261AA	10 mA
WeEn Semiconductors ACTT2X-800E/DGQ	Through Hole	125 ¯C	Single	25 mA	Logic - Sensitive Gate	2 A	800 V	TO-220F	1 V	14 A, 15.4 A	TO-220-3 Full Pack, Isolated Tab	10 mA
WeEn Semiconductors ACTT2X-800E,127	Through Hole	125 ¯C	Single	25 mA	Logic - Sensitive Gate	2 A	800 V	TO-220F	1.5 V	14 A, 15.4 A	TO-220-3 Full Pack, Isolated Tab	10 mA
WeEn Semiconductors ACTT2X-800ETNQ	Through Hole	150 °C	Single	10 mA	Standard	2 A	800 V	TO-220F	2 V	18 A, 20 A	TO-220-3 Full Pack, Isolated Tab	10 mA
WeEn Semiconductors ACTT2S-800E,118	Surface Mount	125 ¯C	Single	25 mA	Logic - Sensitive Gate	2 A	800 V	DPAK	1.5 V	14 A, 15.4 A	DPAK (2 Leads + Tab), SC-63, TO-252-3	10 mA
WeEn Semiconductors ACTT2S-800ETNJ	Surface Mount	150 °C	Single	10 mA	Logic - Sensitive Gate	2 A	800 V	DPAK	1 V	18 A, 19.8 A	DPAK (2 Leads + Tab), SC-63, TO-252-3	10 mA

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

TRIAC Standard 800 V 2 A Surface Mount SC-73
