NLHV25T-R39J-PF
ObsoleteTDK Corporation
FIXED IND 390NH 375MA 730MOHM SM
NLHV25T-R39J-PF
ObsoleteTDK Corporation
FIXED IND 390NH 375MA 730MOHM SM
Description
General part information
NLHV25T-R39J-PF
390 nH Unshielded Wirewound Inductor 375 mA 730mOhm Max Nonstandard
Technical Specifications
Parameters and characteristics for this part
| Specification | NLHV25T-R39J-PF |
|---|---|
| Current Rating | 375 mA |
| DC Resistance (DCR) (Max) | 730 mOhm |
| Frequency - Self Resonant | 375 MHz |
| Height - Seated (Max) | 0.071 in |
| Inductance | 390 nH |
| Inductance Frequency - Test | 25.2 MHz |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Nonstandard |
| Q | 40 |
| Shielding | Unshielded |
| Size / Dimension Length | 0.098 in |
| Size / Dimension Width | 0.079 in |
| Tolerance | 5 % |
| Type | Wirewound |
