Specification	EEU-FS1K820

Applications	General Purpose
Capacitance	82 µF
Height - Seated (Max)	16.51 mm
Impedance	112 mOhms
Lead Spacing	0.138 in
Lifetime	8000 Hrs
Mounting Type	Through Hole
Operating Temperature (Max)	105 °C
Operating Temperature (Min)	-40 °C
Package / Case	Can, Radial
Polarization	Polar
Ripple Current	413 mA, 590 mA
Size / Dimension Diameter	0.315 in
Tolerance	20 %
Voltage - Rated	80 Vp-p

EEU-FS Series

...

Part	Capacitance	Operating Temperature (Min)	Operating Temperature (Max)	Applications	Height - Seated (Max)	Ripple Current	Impedance	Tolerance	Voltage - Rated	Package / Case	Lifetime	Lead Spacing	Polarization	Size / Dimension Diameter	Mounting Type
Panasonic Electronic Components EEU-FS1V272B	2700 µF	-40 °C	105 °C	General Purpose	1.063 in	3.056 A 3.82 A	14 mOhm	20 %	35 V	Can Radial	10000 Hrs	0.295 in	Polar	0.63 in	Through Hole
Panasonic Electronic Components EEU-FS1H270B	27 µF	-40 °C	105 °C	General Purpose	0.492 in	137.5 mA 250 mA	0.34 Ohms	20 %	50 V	Can Radial	5000 Hrs	0.197 in	Polar	0.197 in	Through Hole
Panasonic Electronic Components EEU-FS1J102	1000 µF	-40 °C	105 °C	General Purpose	1.004 in	2.241 A 2.988 A	24 mOhms	20 %	63 V	Can Radial	10000 Hrs	0.295 in	Polar	0.63 in	Through Hole
Panasonic Electronic Components EEU-FS1J181LB	180 µF	-40 °C	105 °C	General Purpose	0.807 in	651 mA 930 mA	50 mOhm	20 %	63 V	Can Radial	9000 Hrs	0.197 in	Polar	0.315 in	Through Hole
Panasonic Electronic Components EEU-FS1K271LB	270 µF	-40 °C	105 °C	General Purpose	1.063 in	1.2 A 840 mA	44 mOhm	20 %	80 Vp-p	Can Radial	10000 Hrs	0.197 in	Polar	0.394 in	Through Hole
Panasonic Electronic Components EEU-FS1J181B	180 µF	-40 °C	105 °C	General Purpose	16.51 mm	1.073 A 751.1 mA	45 mOhm	20 %	63 V	Can Radial	8000 Hrs	0.197 in	Polar	0.394 in	Through Hole
Panasonic Electronic Components EEU-FS2A391	390 µF	-40 °C	105 °C	General Purpose	1.063 in	1.875 A 2.5 A	25 mOhms	20 %	100 VAC/DC	Can Radial	10000 Hrs	0.295 in	Polar	0.63 in	Through Hole
Panasonic Electronic Components EEU-FS1E122B	1200 µF	-40 °C	105 °C	General Purpose	0.866 in	1.744 A 2.18 A	20 mOhm	20 %	25 VAC	Can Radial	10000 Hrs	0.197 in	Polar	0.394 in	Through Hole
Panasonic Electronic Components EEU-FS2A270	27 µF	-40 °C	105 °C	General Purpose	0.512 in	269.5 mA 490 mA	0.16 Ohms	20 %	100 VAC/DC	Can Radial	6000 Hrs	0.138 in	Polar	0.315 in	Through Hole
Panasonic Electronic Components EEU-FS1K470	47 µF	-40 °C	105 °C	General Purpose	0.512 in	343 mA 490 mA	0.16 Ohms	20 %	80 Vp-p	Can Radial	6000 Hrs	0.138 in	Polar	0.315 in	Through Hole

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

Alum Elect Cap, Safety Precautions

EEU-FS1K820 | Datasheet
