SM2511-1R0MHF
ActiveITG Electronics, Inc.
FIXED IND 1UH 11A 10 MOHM SMD
SM2511-1R0MHF
ActiveITG Electronics, Inc.
FIXED IND 1UH 11A 10 MOHM SMD
Description
General part information
SM2511-1R0MHF
1 µH Shielded Molded Inductor 11 A 10mOhm Max Nonstandard
Technical Specifications
Parameters and characteristics for this part
| Specification | SM2511-1R0MHF |
|---|---|
| Current - Saturation (Isat) | 22 A |
| Current Rating | 11 A |
| DC Resistance (DCR) (Max) | 10 mOhm |
| Height - Seated (Max) | 0.118 in |
| Inductance | 1 µH |
| Inductance Frequency - Test | 100 kHz |
| Material - Core | Metal |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Nonstandard |
| Shielding | Shielded |
| Size / Dimension Length | 0.263 in |
| Size / Dimension Width | 0.255 in |
| Tolerance | 20 % |
| Type | Molded |
