FC6A Series

...

Part	For Use With/Related Products	Type	Mounting Type	Approval Agency	Operating Temperature (Min)	Operating Temperature (Max)	Ingress Protection	Display Type	Voltage - Supply	Memory Size	Features	Communications	Number of Outputs	Output Type	Number of Inputs	Input Types	Expandable	Accessory Type	Voltage - Supply (Minimum)	Voltage - Supply (Maximum)	Maximum Expandable Modules	Features - Starter Kit	Termination Style	Specifications	Solid State Output Count
IDEC FC6A-HPH1	FC6A Series	Cartridge Base Module	DIN Rail
IDEC FC6A-C40R1DEJ			DIN Rail	CE cULus	-10 °C	55 °C	IP20	No Display	12 VDC	640 KB	Battery Backup (Lithium)	CAN Ethernet USB	16	Relay	24	Digital	Non-Expandable
IDEC FC6A-PMSCK11PN02	Multiple Series																	Module
IDEC FC6A-PMTC10PN02	Multiple Series																	Module
IDEC FC6A-C40R4CEJ			DIN Rail Panel Mount							2 GByte		Ethernet RS-232C RS-485 USB					Expandable		12 VDC	24 VAC
IDEC FC6A-D32P3CEE			DIN Rail					No Display	24 VDC	800 KB	Battery Backup (Lithium)	Ethernet USB	16	Solid State	16	Digital					7 Modules
IDEC KIT-FC6A-C24R-HG3G-V8HP			DIN Rail					TFT - Color LCD	24 VDC								Expandable					Cable Manual Power Supply
IDEC FC6A-R081	FC6A Series	Output Module	DIN Rail	CE cULus	-10 °C	55 °C	IP20		24 VDC				8	Relay									Pluggable Screw Terminal
IDEC FC6A-PTS4	FC6A and FT1A Series																	Option Card Output						Solid State	4
IDEC FC6A-T16P4	FC6A Series	Output Module	Spring Terminal						24 VDC				16	Solid State									Spring Terminal

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

3D models and CAD resources for this part

Technical documentation and resources
