Specification	25LC010AT-H/SN

Clock Frequency	10 MHz
Memory Depth	128
Memory Format	EEPROM
Memory Interface (Type)	SPI
Memory Size	1 Kbit
Memory Type	Non-Volatile
Memory Width	8 bit
Mounting Type	Surface Mount
Operating Temperature (Max)	150 °C
Operating Temperature (Min)	-40 °C
Package Length	0.154 in
Package Name	8-SOIC
Package Width	3.9 mm
Technology	EEPROM
Voltage - Supply (Maximum)	5.5 V
Voltage - Supply (Minimum)	2.5 V
Write Cycle Time - Page	5 ms
Write Cycle Time - Word	5 ms

25LC010A Series

Part	Voltage - Supply (Minimum)	Voltage - Supply (Maximum)	Operating Temperature (Max)	Operating Temperature (Min)	Clock Frequency	Memory Depth	Memory Width	Memory Type	Write Cycle Time - Word	Write Cycle Time - Page	Memory Size	Mounting Type	Package Name	Technology	Memory Format	Memory Interface (Type)	Package Length	Package Width	Qualification	Grade
Microchip Technology 25LC010A-I/ST	2.5 V	5.5 V	85 °C	-40 °C	10 MHz	128	8 bit	Non-Volatile	5 ms	5 ms	1 Kbit	Surface Mount	8-TSSOP	EEPROM	EEPROM	SPI	0.173 in	4.4 mm
Microchip Technology 25LC010AT-E/SN16KVAO	2.5 V	5.5 V	125 °C	-40 °C	10 MHz	128	8 bit	Non-Volatile	5 ms	5 ms	1 Kbit	Surface Mount	8-SOIC	EEPROM	EEPROM	SPI	0.154 in	3.9 mm	AEC-Q100	Automotive
Microchip Technology 25LC010A-I/P	2.5 V	5.5 V	85 °C	-40 °C	10 MHz	128	8 bit	Non-Volatile	5 ms	5 ms	1 Kbit	Through Hole	8-DIP 8-PDIP	EEPROM	EEPROM	SPI	0.3 in	7.62 mm
Microchip Technology 25LC010AT-E/MS	2.5 V	5.5 V	125 °C	-40 °C	10 MHz	128	8 bit	Non-Volatile	5 ms	5 ms	1 Kbit	Surface Mount	8-MSOP 8-TSSOP 8-MSOP	EEPROM	EEPROM	SPI	0.118 in	3 mm
Microchip Technology 25LC010A-E/P	2.5 V	5.5 V	125 °C	-40 °C	10 MHz	128	8 bit	Non-Volatile	5 ms	5 ms	1 Kbit	Through Hole	8-DIP 8-PDIP	EEPROM	EEPROM	SPI	0.3 in	7.62 mm
Microchip Technology 25LC010A-E/SN16KVAO	2.5 V	5.5 V	125 °C	-40 °C	10 MHz	128	8 bit	Non-Volatile	5 ms	5 ms	1 Kbit	Surface Mount	8-SOIC	EEPROM	EEPROM	SPI	0.154 in	3.9 mm	AEC-Q100	Automotive
Microchip Technology 25LC010AT-E/ST	2.5 V	5.5 V	125 °C	-40 °C	10 MHz	128	8 bit	Non-Volatile	5 ms	5 ms	1 Kbit	Surface Mount	8-TSSOP	EEPROM	EEPROM	SPI	0.173 in	4.4 mm
Microchip Technology 25LC010AT-I/ST	2.5 V	5.5 V	85 °C	-40 °C	10 MHz	128	8 bit	Non-Volatile	5 ms	5 ms	1 Kbit	Surface Mount	8-TSSOP	EEPROM	EEPROM	SPI	0.173 in	4.4 mm
Microchip Technology 25LC010A-E/ST	2.5 V	5.5 V	125 °C	-40 °C	10 MHz	128	8 bit	Non-Volatile	5 ms	5 ms	1 Kbit	Surface Mount	8-TSSOP	EEPROM	EEPROM	SPI	0.173 in	4.4 mm
Microchip Technology 25LC010A-I/MS	2.5 V	5.5 V	85 °C	-40 °C	10 MHz	128	8 bit	Non-Volatile	5 ms	5 ms	1 Kbit	Surface Mount	8-MSOP 8-TSSOP 8-MSOP	EEPROM	EEPROM	SPI	0.118 in	3 mm
