Specification	ERM8-060-05.0-S-DV-K-TR

Connector Type	Header, Center Strip Contacts
Contact Finish	Gold
Contact Finish Thickness	30 µin
Features	Board Guide, Pick and Place
Height Above Board	0.351 in
Mated Stacking Height Options	10mm, 15mm, 12mm
Mounting Type	Surface Mount
Number of Positions	120
Number of Rows	2
Pitch	0.031 in

ERM8-060 Series

Part	Features	Mounting Type	Mated Stacking Height Options	Pitch	Connector Type	Height Above Board	Number of Rows	Number of Positions	Contact Finish	Contact Finish Thickness
Samtec Inc. ERM8-060-05.0-S-DV-L-K-TR	Board Guide Latches Pick and Place	Surface Mount	10mm 12mm 15mm	0.031 in	Center Strip Contacts Header	0.351 in	2	120	Gold	30 µin
Samtec Inc. ERM8-060-01-L-D-EM2-DSS-TR	Mating Guide	Board Edge Straddle Mount		0.031 in	Differential Pair Array MALE		2	120	Gold	10 Ąin
Samtec Inc. ERM8-060-01-S-D-RA-L-K-TR	Board Guide Latches Mounting Flange Pick and Place	Right Angle Surface Mount		0.031 in	Center Strip Contacts Header	0.246 in	2	120	Gold	30 µin
Samtec Inc. ERM8-060-01-L-D-EM2-SL-TR	Latches	Board Edge Straddle Mount		0.031 in	Center Strip Contacts Header		2	120	Gold	10 Ąin
Samtec Inc. ERM8-060-01-S-D-RA-K-TR	Board Guide Pick and Place	Right Angle Surface Mount		0.031 in	Center Strip Contacts Header	0.246 in	2	120	Gold	30 µin
Samtec Inc. ERM8-060-05.0-S-DV-L-TR	Board Guide Latches	Surface Mount	10mm 12mm 15mm	0.031 in	Center Strip Contacts Header	0.351 in	2	120	Gold	30 µin
Samtec Inc. ERM8-060-05.0-L-DV-EGP-K-TR	Board Guide Mating Guide Pick and Place	Surface Mount	10mm 12mm 15mm	0.031 in	Center Strip Contacts Header	0.351 in	2	120	Gold	10 Ąin
Samtec Inc. ERM8-060-01-S-D-RA-L-TR	Board Guide Latches Mounting Flange	Right Angle Surface Mount		0.031 in	Center Strip Contacts Header	0.246 in	2	120	Gold	30 µin
Samtec Inc. ERM8-060-02.0-L-DV-K-TR	Board Guide Pick and Place	Surface Mount	12mm 7mm 9mm	0.031 in	Center Strip Contacts Header	0.235 in	2	120	Gold	10 Ąin
Samtec Inc. ERM8-060-01-L-D-RA-L-K-TR	Board Guide Latches Mounting Flange Pick and Place	Right Angle Surface Mount		0.031 in	Center Strip Contacts Header	0.246 in	2	120	Gold	10 Ąin
