Specification	DX10M-68S(50)

Connector Style	Outer Shroud Contacts
Connector Type	Receptacle
Contact Finish	Gold
Contact Finish Thickness	11.8 µin
Flange Feature	Shell (M2.6), Housing
Mounting Type	Panel Mount, Through Hole, Right Angle
Number of Positions	68
Number of Rows	2
Termination	Solder
Type	Miniature High Density (HD)

DX10 Series

Part	Type	Number of Positions	Contact Finish Thickness	Connector Type	Connector Style	Number of Rows	Flange Feature	Mounting Type	Contact Finish	Termination	Features
Hirose Electric Co Ltd DX10-28S(50)	Miniature High Density (HD)	28	7.87 µin	Receptacle	Outer Shroud Contacts	2	Housing Latchblocks Shell (M2.6)	Panel Mount Right Angle Through Hole	Gold	Solder
Hirose Electric Co Ltd DX10AM-110SE2(50)	Miniature High Density (HD)	110	7.87 µin	Receptacle	Outer Shroud Contacts	2	Female Screwlock (M2.6) Mating Side	Panel Mount Right Angle Through Hole	Gold	Solder	Board Lock
Hirose Electric Co Ltd DX10BM-68S(50)	Miniature High Density (HD)	68		Receptacle	Outer Shroud Contacts	2	Female Screwlock (M2.6) Mating Side	Panel Mount Right Angle Through Hole	Gold	Solder
Hirose Electric Co Ltd DX10A-28S(50)	Miniature High Density (HD)	28	7.87 µin	Receptacle	Outer Shroud Contacts	2	Female Screwlock (M2.6) Mating Side	Panel Mount Right Angle Through Hole	Gold	Solder
Hirose Electric Co Ltd DX10M-14S(50)	Miniature High Density (HD)	14	11.8 µin	Receptacle	Outer Shroud Contacts	2	Housing Latchblocks Shell (M2.6)	Panel Mount Right Angle Through Hole	Gold	Solder
Hirose Electric Co Ltd DX10M-20S(50)	Miniature High Density (HD)	20	11.8 µin	Receptacle	Outer Shroud Contacts	2	Housing Shell (M2.6)	Panel Mount Right Angle Through Hole	Gold	Solder
Hirose Electric Co Ltd DX10G1M-50S(50)	Miniature High Density (HD)	50		Receptacle	Outer Shroud Contacts	2	Housing Shell (M2.6)	Panel Mount Right Angle Through Hole	Gold	Solder
Hirose Electric Co Ltd DX10G1M-14S(50)	Miniature High Density (HD)	14		Receptacle	Outer Shroud Contacts	2	Housing Shell (M2.6)	Panel Mount Right Angle Through Hole	Gold	Solder
Hirose Electric Co Ltd DX10-80S(50)	Miniature High Density (HD)	80	7.87 µin	Receptacle	Outer Shroud Contacts	2	Housing Latchblocks Shell (M2.6)	Panel Mount Right Angle Through Hole	Gold	Solder
Hirose Electric Co Ltd DX10M-20SE(50)	Miniature High Density (HD)	20	11.8 µin	Receptacle	Outer Shroud Contacts	2	Latchblocks Mating Side (M2.6)	Panel Mount Right Angle Through Hole	Gold	Solder	Board Lock
