7916-44FYA
ActiveOupiin
CONN D-SUB HD RCPT 44P R/A SLDR
Deep-Dive with AI
Search across all available documentation for this part.
7916-44FYA
ActiveOupiin
CONN D-SUB HD RCPT 44P R/A SLDR
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 7916-44FYA |
|---|---|
| Backset Spacing | 8.89 mm |
| Backset Spacing | 0.35 in |
| Color | Black |
| Connector Style | High Density, D-Sub |
| Connector Type | Receptacle, Female Sockets |
| Contact Finish | Gold |
| Contact Material | Brass |
| Contact Type | Signal |
| Dielectric Material | Polybutylene Terephthalate (PBT) |
| Flange Feature | Female Screwlock (4-40), Mating Side |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Through Hole, Right Angle |
| Number of Positions | 44 |
| Number of Rows | 3 |
| Operating Temperature [Max] | 105 ░C |
| Operating Temperature [Min] | -55 °C |
| Shell Material, Finish | Nickel Plated, Steel |
| Shell Size, Connector Layout [custom] | B, DB |
| Shell Size, Connector Layout [x] | 3 |
| Termination | Solder |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 1 | $ 6.18 | |
| 150 | $ 5.77 | |||
| 300 | $ 5.15 | |||
| 450 | $ 4.12 | |||
| 600 | $ 3.30 | |||
Description
General part information
7916-44FYA
44 Position D-Sub, High Density Receptacle, Female Sockets Connector
Documents
Technical documentation and resources
No documents available
