1815248
ActivePhoenix Contact
CONN HEADER 7POS 2.5MM SMD
1815248
ActivePhoenix Contact
CONN HEADER 7POS 2.5MM SMD
Description
General part information
1815248
SSL Connector 7 Position Header, Female Sockets Board to Cable/Wire 0.098" (2.50mm) Solder
Technical Specifications
Parameters and characteristics for this part
| Specification | 1815248 |
|---|---|
| Connector Type | Female Sockets, Header |
| Contact Finish | Tin |
| Current Rating | 5 A |
| Fastening Type | Detent Lock |
| Features | Solder Retention |
| Housing Color | White |
| Housing Material | Nylon, Polyamide, PA |
| Mounting Type | Right Angle, Surface Mount |
| Number of Positions | 7 |
| Pitch | 0.098 in |
| Style | Cable/Wire, Board |
| Termination | Solder |
| Voltage Rating | 150 VDC |
