Specification	B43501A1108M000

Applications	General Purpose
Capacitance	1000 µF
ESR (Equivalent Series Resistance)	120 mOhm
Height - Seated (Max)	1.457 in
Impedance	0.16 Ohms
Lead Spacing	0.394 in
Lifetime	10000 Hrs
Mounting Type	Through Hole
Operating Temperature (Max)	85 °C
Operating Temperature (Min)	-40 °C
Package / Case	Can - Snap-In, Radial
Polarization	Polar
Ripple Current	3.12 A
Size / Dimension Diameter	1.181 in
Tolerance	20 %
Voltage - Rated	160 V

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Technical documentation and resources
