CY7C199C-15ZC

Obsolete

Infineon Technologies

IC SRAM 256KBIT PAR 28TSOP I

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

CY7C199C-15ZC

Obsolete

Infineon Technologies

IC SRAM 256KBIT PAR 28TSOP I

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	CY7C199C-15ZC

Access Time	15 ns
Memory Format	SRAM
Memory Interface	Parallel
Memory Organization	32K x 8
Memory Size	32 KB
Memory Type	Volatile
Mounting Type	Surface Mount
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	0 °C
Package / Case	28-TSSOP
Package / Case [x]	0.465 "
Package / Case [y]	11.8 mm
Supplier Device Package	28-TSOP I
Technology	SRAM - Asynchronous
Voltage - Supply [Max]	5.5 V
Voltage - Supply [Min]	4.5 V
Write Cycle Time - Word, Page	15 ns

CY7C199 Series

Part	Memory Organization	Memory Format	Memory Type	Technology	Memory Interface	Write Cycle Time - Word, Page	Supplier Device Package	Memory Size	Voltage - Supply [Min]	Voltage - Supply [Max]	Package / Case [y]	Package / Case [x]	Package / Case	Access Time	Mounting Type	Operating Temperature [Max]	Operating Temperature [Min]	Package / Case	Package / Case	Package / Case
Infineon Technologies CY7C199NL-15ZXCT	32K x 8	SRAM	Volatile	SRAM - Asynchronous	Parallel	15 ns	28-TSOP I	32 KB	4.5 V	5.5 V	11.8 mm	0.465 "	28-TSSOP	15 ns	Surface Mount	70 °C	0 °C
Infineon Technologies CY7C199CN-15ZXC	32K x 8	SRAM	Volatile	SRAM - Asynchronous	Parallel	15 ns	28-TSOP I	32 KB	4.5 V	5.5 V	11.8 mm	0.465 "	28-TSSOP	15 ns	Surface Mount	70 °C	0 °C
Infineon Technologies CY7C199C-15ZC	32K x 8	SRAM	Volatile	SRAM - Asynchronous	Parallel	15 ns	28-TSOP I	32 KB	4.5 V	5.5 V	11.8 mm	0.465 "	28-TSSOP	15 ns	Surface Mount	70 °C	0 °C
Infineon Technologies CY7C199CNL-15VXCT	32K x 8	SRAM	Volatile	SRAM - Asynchronous	Parallel	15 ns	28-SOJ	32 KB	4.5 V	5.5 V			28-BSOJ	15 ns	Surface Mount	70 °C	0 °C	7.62 mm	0.3 in
Infineon Technologies CY7C199C-15VXCT	32K x 8	SRAM	Volatile	SRAM - Asynchronous	Parallel	15 ns	28-SOJ	32 KB	4.5 V	5.5 V			28-BSOJ	15 ns	Surface Mount	70 °C	0 °C	7.62 mm	0.3 in
Infineon Technologies CY7C199CN-20ZXI	32K x 8	SRAM	Volatile	SRAM - Asynchronous	Parallel	20 ns	28-TSOP I	32 KB	4.5 V	5.5 V	11.8 mm	0.465 "	28-TSSOP	20 ns	Surface Mount	85 °C	-40 °C
Infineon Technologies CY7C199D-10ZXIT	32K x 8	SRAM	Volatile	SRAM - Asynchronous	Parallel	10 ns	28-TSOP I	32 KB	4.5 V	5.5 V	11.8 mm	0.465 "	28-TSSOP	10 ns	Surface Mount	85 °C	-40 °C
Infineon Technologies CY7C199C-25PC	32K x 8	SRAM	Volatile	SRAM - Asynchronous	Parallel	25 ns	28-PDIP	32 KB	4.5 V	5.5 V			28-DIP	25 ns	Through Hole	70 °C	0 °C	0.3 in		7.62 mm
Infineon Technologies CY7C199CN-25PXC	32K x 8	SRAM	Volatile	SRAM - Asynchronous	Parallel	25 ns	28-PDIP	32 KB	4.5 V	5.5 V			28-DIP	25 ns	Through Hole	70 °C	0 °C	0.3 in		7.62 mm
Infineon Technologies CY7C199CL-15VXCT	32K x 8	SRAM	Volatile	SRAM - Asynchronous	Parallel	15 ns	28-SOJ	32 KB	4.5 V	5.5 V			28-BSOJ	15 ns	Surface Mount	70 °C	0 °C	7.62 mm	0.3 in

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bag	468	$ 0.64
		468	$ 0.64

Description

General part information

CY7C199 Series

SRAM - Asynchronous Memory IC 256Kbit Parallel 15 ns 28-TSOP I
