1038AS201KDS

Active

Ohmite

RES CHAS MNT 200 OHM 10% 225W

Search across all available documentation for this part.

Active

Ohmite

RES CHAS MNT 200 OHM 10% 225W

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

200 Ohms ±10% 225W Ceramic Chassis Mount Resistor

Technical documentation and resources

No documents available

Parameters and characteristics commom to parts in this series

Specification	1038AS201KDS	1038AS Series

Coating, Housing Type	Ceramic	Ceramic
Composition	Ceramic	Ceramic
Features	Non-Inductive, High Voltage, Pulse Withstanding	Non-Inductive, High Voltage, Pulse Withstanding
Lead Style	Ferrule Ends	Ferrule Ends
Mounting Feature	Brackets (not included)	Brackets (not included)
Operating Temperature [Max]	230 °C	230 °C
Operating Temperature [Min]	-55 °C	-55 °C
Package / Case	Axial, Tubular	Axial, Tubular
Power (Watts)	225 W	225 W
Resistance	200 Ohms	75 - 200 Ohms
Size / Dimension	38.1 mm, 457.2 mm	38.1 - 457.2 mm
Size / Dimension [custom]	18 in	18 in
Size / Dimension [diameter]	1.5 in	1.5 in
Temperature Coefficient	-800 ppm/°C, 0 ppm/°C	-800 - 0 ppm/°C
Tolerance	10 %	10 %

RES CHAS MNT 200 OHM 10% 225W

Part	Power (Watts)	Package / Case	Size / Dimension	Size / Dimension [diameter]	Size / Dimension [custom]	Features	Mounting Feature	Coating, Housing Type	Operating Temperature [Max]	Operating Temperature [Min]	Resistance	Temperature Coefficient	Tolerance	Composition	Lead Style
Ohmite 1038AS201KDS	225 W	Axial, Tubular	38.1 mm, 457.2 mm	1.5 in	18 in	High Voltage, Non-Inductive, Pulse Withstanding	Brackets (not included)	Ceramic	230 °C	-55 °C	200 Ohms	-800 ppm/°C, 0 ppm/°C	10 %	Ceramic	Ferrule Ends
Ohmite 1038AS750KDS	225 W	Axial, Tubular	38.1 mm, 457.2 mm	1.5 in	18 in	High Voltage, Non-Inductive, Pulse Withstanding	Brackets (not included)	Ceramic	230 °C	-55 °C	75 Ohms	-800 ppm/°C, 0 ppm/°C	10 %	Ceramic	Ferrule Ends
