Molex

MICRO-FIT+ VERTICAL HEADER, THROUGH HOLE, 3.00MM PITCH, SINGLE ROW, 4 CIRCUITS, MATTE TIN (SN) PLATING, GLOW-WIRE CAPABLE, BLACK

Find alt
2165711004

2165711004

Active
Molex

MICRO-FIT+ VERTICAL HEADER, THROUGH HOLE, 3.00MM PITCH, SINGLE ROW, 4 CIRCUITS, MATTE TIN (SN) PLATING, GLOW-WIRE CAPABLE, BLACK

Find alt

Description

General part information

216571 Series

Connector Header Through Hole 4 position 0.118" (3.00mm)

Technical Specifications

Parameters and characteristics for this part

Specification2165711004
Connector TypeHeader
Contact Finish - MatingTin
Contact Finish - PostTin
Contact Length - Post0.125 in
Contact MaterialCopper Alloy
Contact ShapeSquare
Contact TypeMale Pin
Current Rating0 A
Current RatingVaries by Wire Gauge
Fastening TypeLocking Ramp
FeaturesBoard Guide, Glow Wire Compliant
Insulation ColorBlack
Insulation Height0.39 in
Insulation MaterialGlass Filled, Liquid Crystal Polymer (LCP)
Material Flammability RatingUL94 V-0
Mounting TypeThrough Hole
Number of Positions4
Number of Positions LoadedAll
Number of Rows1
Operating Temperature (Max)105 °C
Operating Temperature (Min)-40 °C
Pitch - Mating0.118 in
ShroudingShrouded - 4 Wall
StyleCable/Wire, Board
TerminationSolder
Voltage Rating600 V
Voltage Rating (Type)DC
