A-HBM16AT-2
ActiveAssmann WSW Components
DIN41612, M, STYLE B/2, 16,
A-HBM16AT-2
ActiveAssmann WSW Components
DIN41612, M, STYLE B/2, 16,
Description
General part information
A-HBM16AT-2
16 Position Din Connector Header, Male Pins Gold Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | A-HBM16AT-2 |
|---|---|
| Connector Type | Header, Male Pins |
| Contact Finish | Gold |
| Contact Finish Thickness | 15 µin |
| Current Rating | 2 A |
| Features | Polarizing Key |
| Level, Class | 2 |
| Material - Insulation | Glass Filled, PBT, Polybutylene Terephthalate |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Through Hole |
| Number of Positions | 16 |
| Number of Positions Loaded | All |
| Number of Rows | 1 |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -40 °C |
| Pitch | 0.1 in |
| Style | B/2 (1/2 B) |
| Termination | Solder |
