B43612A5338M050
ActiveEPCOS - TDK Electronics
CAP ALUM 3.3MF 20% 450V SNAP TH
B43612A5338M050
ActiveEPCOS - TDK Electronics
CAP ALUM 3.3MF 20% 450V SNAP TH
Description
General part information
B43612A5338M050
3.3 mF 450 V Aluminum Electrolytic Capacitors Radial, Can - Snap-In - 5 Lead 40mOhm @ 100Hz 10000 Hrs @ 85°C
Technical Specifications
Parameters and characteristics for this part
| Specification | B43612A5338M050 |
|---|---|
| Applications | General Purpose |
| Capacitance | 3.3 mF |
| ESR (Equivalent Series Resistance) | 40 mOhm |
| Height - Seated (Max) | 4.213 in |
| Impedance | 65 mOhms |
| Lead Spacing | 0.984 in |
| Lifetime | 10000 Hrs |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Package Leads | 5 Lead |
| Package Name | Can - Snap-In, Radial |
| Polarization | Polar |
| Ripple Current | 13.5 A |
| Size / Dimension Diameter | 1.969 in |
| Tolerance | 20 % |
| Voltage - Rated | 450 V |
