RISH FLEX - E 4512A
AC/DC DIN RAIL SUPPLY 12V 6.2W
Technical Specifications
Parameters and characteristics for this part
| Specification | RISH FLEX - E 4512A |
|---|---|
| AC Voltage - Input (Max) | 264 VAC |
| AC Voltage - Input (Min) | 85 VAC |
| Applications | ITE (Commercial) |
| Current - Output (Max) | 3.75 A |
| DC Voltage - Input (Max) | 370 V |
| DC Voltage - Input (Min) | 120 V |
| Efficiency | 87 % |
| Features | Adjustable Output, DC Input Capable |
| Input Type | AC or DC, DC, AC |
| Number of Outputs | 1 |
| Operating Temperature (Max) | 70 °C |
| Operating Temperature (Min) | -30 °C |
| Size / Dimension Height | 3.54 in |
| Size / Dimension Length | 2.44 in |
| Size / Dimension Width | 2.13 in |
| Standard Number | 60950-1 |
| Voltage - Isolation | 3 kV |
| Voltage - Output 1 | 12 V |
