BDCDR000000S00
ActiveNextGen Components
RED TOP LED PLCC-2
BDCDR000000S00
ActiveNextGen Components
RED TOP LED PLCC-2
Description
General part information
BDCDR000000S00
Red 620nm LED Indication - Discrete 1411 (3528 Metric)
Technical Specifications
Parameters and characteristics for this part
| Specification | BDCDR000000S00 |
|---|---|
| Color | Red |
| Configuration | Standard |
| Current - Test | 20 mA |
| Grade | Automotive |
| Height (Max) | 1.95 mm |
| Lens Color | Colorless |
| Lens Diameter | 2.5 mm |
| Lens Style | Round, Domed Top |
| Lens Transparency | Clear |
| Millicandela Rating | 5740 mcd |
| Mounting Type | Surface Mount |
| Package / Case | 1411 (3528 Metric) |
| Package Diameter | 3528 mm |
| Package Name | P-LCC-2, 1411 |
| Size / Dimension Length | 3.5 mm |
| Size / Dimension Width | 2.8 mm |
| Viewing Angle | 30 ° |
| Wavelength - Dominant | 620 nm |
| Wavelength - Peak | 632 nm |
