ART-B22-D175

Active

LEM USA Inc.

CURR SENSE XFMR FLEXIBLE COIL

Search across all available documentation for this part.

Active

LEM USA Inc.

CURR SENSE XFMR FLEXIBLE COIL

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	ART-B22-D175	ART-B22 Series

DC Resistance (DCR)	105 Ohm	55 - 170 Ohm
Frequency Range [Max]	60 Hz	60 Hz
Frequency Range [Min]	50 Hz	50 Hz
Height - Seated (Max) [Max] [z]	0.744 "	0.744 "
Height - Seated (Max) [Max] [z]	18.91 mm	18.91 mm
Inductance	343 µH	180 - 566 µH
Mounting Type	Free Hanging (In-Line)	Free Hanging (In-Line)
Size / Dimension [x]	2.205 in	2.205 in
Size / Dimension [x]	56.01 mm	56.01 mm
Size / Dimension [y]	1.326 "	1.326 "
Size / Dimension [y]	33.69 mm	33.69 mm
Termination Style	Wire Leads	Wire Leads 1.5m, Wire Leads
Turns Ratio - Primary:Secondary	Rogowski Coil	Rogowski Coil
Type	Non-Invasive (Split Core)	Non-Invasive (Split Core)

CURR SENSE XFMR FLEXIBLE COIL

Part	DC Resistance (DCR)	Inductance	Termination Style	Mounting Type	Type	Turns Ratio - Primary:Secondary	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Frequency Range [Max]	Frequency Range [Min]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]
LEM USA Inc. ART-B22-D70	55 Ohm	180 µH	Wire Leads 1.5m	Free Hanging (In-Line)	Non-Invasive (Split Core)	Rogowski Coil	0.744 "	18.91 mm	60 Hz	50 Hz	1.326 "	33.69 mm	2.205 in	56.01 mm
LEM USA Inc. ART-B22-D300	170 Ohm	566 µH	Wire Leads	Free Hanging (In-Line)	Non-Invasive (Split Core)	Rogowski Coil	0.744 "	18.91 mm	60 Hz	50 Hz	1.326 "	33.69 mm	2.205 in	56.01 mm
LEM USA Inc. ART-B22-D175	105 Ohm	343 µH	Wire Leads	Free Hanging (In-Line)	Non-Invasive (Split Core)	Rogowski Coil	0.744 "	18.91 mm	60 Hz	50 Hz	1.326 "	33.69 mm	2.205 in	56.01 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Rogowski Coil Current Sense Transformer 50/60Hz 105Ohm 343 µH Free Hanging (In-Line)
