BU-3131-A-12-2

Active

Mueller Electric Co

TEST LEAD, ALLIGATOR CLIP TO ALLIGATOR CLIP, RED, 5 A, 304.8 MM

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsTechnical Data Sheet EN Datasheet

BU-3131-A-12-2

Active

Mueller Electric Co

TEST LEAD, ALLIGATOR CLIP TO ALLIGATOR CLIP, RED, 5 A, 304.8 MM

Deep-Dive with AI

DocumentsTechnical Data Sheet EN Datasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	BU-3131-A-12-2

1st Connector	Insulated, Miniature, Alligator Clip
2nd Connector	Insulated, Miniature, Alligator Clip
Cable Length	12 in
Cable Length	304.8 mm
Contents	Red
Contents [custom]	1
Current Rating (Amps)	5 A
Material - Insulation	Poly-Vinyl Chloride (PVC)
Temperature Range	105 °C
Temperature Range	221 °F
Voltage - Rated	300 V
Wire Gauge	20 AWG

BU-3131 Series

Part	1st Connector	Material - Insulation	Voltage - Rated	Cable Length	Cable Length	Wire Gauge	Current Rating (Amps)	Contents [custom]	Contents	2nd Connector	Temperature Range	Temperature Range
Mueller Electric Co BU-3131-A-60-2	Alligator Clip Insulated Miniature	Poly-Vinyl Chloride (PVC)	300 V	1524 mm	5 ft	20 AWG	5 A	1	Red	Alligator Clip Insulated Miniature	105 °C	221 °F
Mueller Electric Co BU-3131-A-36-0	Alligator Clip Insulated Miniature	Poly-Vinyl Chloride (PVC)	300 V	914.4 mm	36 in	20 AWG	5 A		1 Lead Black	Alligator Clip Insulated Miniature	105 °C	221 °F
Mueller Electric Co BU-3131-A-60-0	Alligator Clip Insulated Miniature	Poly-Vinyl Chloride (PVC)	300 V	1524 mm	5 ft	20 AWG	5 A		1 Lead Black	Alligator Clip Insulated Miniature	105 °C	221 °F
Mueller Electric Co BU-3131-A-36-2	Alligator Clip Insulated Miniature	Poly-Vinyl Chloride (PVC)	300 V	914.4 mm	36 in	20 AWG	5 A	1	Red	Alligator Clip Insulated Miniature	105 °C	221 °F
Mueller Electric Co BU-3131-A-12-0	Alligator Clip Insulated Miniature	Poly-Vinyl Chloride (PVC)	300 V	304.8 mm	12 in	20 AWG	5 A		1 Lead Black	Alligator Clip Insulated Miniature	105 °C	221 °F
Mueller Electric Co BU-3131-A-12-2	Alligator Clip Insulated Miniature	Poly-Vinyl Chloride (PVC)	300 V	304.8 mm	12 in	20 AWG	5 A	1	Red	Alligator Clip Insulated Miniature	105 °C	221 °F
Mueller Electric Co BU-3131-A-24-0	Alligator Clip Insulated Miniature	Poly-Vinyl Chloride (PVC)	300 V	609.6 mm	24 "	20 AWG	5 A		1 Lead Black	Alligator Clip Insulated Miniature	105 °C	221 °F
Mueller Electric Co BU-3131-A-24-2	Alligator Clip Insulated Miniature	Poly-Vinyl Chloride (PVC)	300 V	609.6 mm	24 "	20 AWG	5 A	1	Red	Alligator Clip Insulated Miniature	105 °C	221 °F
Mueller Electric Co BU-3131-A-48-2	Alligator Clip Insulated Miniature	Poly-Vinyl Chloride (PVC)	300 V	1219.2 mm	48 in	20 AWG	5 A	1	Red	Alligator Clip Insulated Miniature	105 °C	221 °F

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 8.56
Newark	Each	100	$ 9.40

Description

General part information

BU-3131 Series

The BU-3131-A-12-2 is a Test Lead with insulated mini-alligator clip on both ends. It accepts 20AWG tinned copper with 105°C PVC insulation hook-up wire. The alligator clip made of nickel-plated steel with PVC insulator.

Documents

Technical documentation and resources

Technical Data Sheet EN

Datasheet
